Quality
Positioning accuracy: 0.02mm
Repetition accuracy: 0.02mm
Equipment
@ Readily removable die set
@ Max 5 levels lower pressing platens
@ Max 2 levels upper punch closed loop controlled
@ Lower core rod closed loop or open loop controlled
Productivity
Quick moulding rates and can be infinitely adjusted within its range
Energy Consumption
The combination of penumatic and machanical mechanism result in minimal and green energy consumption.
Key Features
1. Rigid and compact
2. Oil bath to ensure maximum smoothness of running and minimum wear
3. Automatic filler drive
4. Very good access to filling system
5. With progressive adjustable underfill/overfill
6. Attachment of Automation Equip possible
7. The revolutionary floating platen pressing system
8. On the basis of proportional pressing technology
9. The respective stop-position of(pressing, ejection and filling) are in high stop accuracy
10. Powder filling compensation and transferring function
11. Compaction with even density and without crack (ejection holding technology)
12. Real-time production and quality monitoring
13. Dynamic core rod system
14. User-friendly HMI
15. PLC controlling system
16. Special design based on customized solution
Technical Parameters:
1. Max pressing capacity: 1200KN
2. Max ejection capacity: 600KN
3. Max die withdrawing pressure: 600KN
4. Max die return force: 13.5KN
5. Upper punch stroke: 200mm
6. Upper punch adjustment: 100mm
7. Max depth of filling: 150mm
8. Max pressing stroke: 50mm
9. Max ejection stroke: 100mm
10. Max top pressing stroke: 10mm
11. Over (under) filling stroke: 7.5mm
12. Die ejection level adjustment: +-7.5
13. Max compact diameter: 120mm
14. Strokes per minute: 6-24
15Type of feeding device: Straight cam vibration
16. Feeder stroke: 170mm
17. Powder hopper: 55L
18. Type of upper punch adjustment: Manual
19. Type of filling adjustment: Manual
20. Type of ejection adjustment: Manual
21. Type of top pressing adjustment: Manual
22. Type of Lubrication: Motorized oil pump
23. Speed chang device: Inverter
24. Clutch&brake: Air Clutch
25. Required air presure: 0.5-0.7 Mpa
26. Air consumption: 300L/min
27. Main motor powder: 18.5kw
