Drawing Process:
MATERIAL QUALITY CONTROL-DRILING &WELDING-POLISHING/PAINTING-ASSEMBLING-ELECTRICAL ASSEMBLING-DEBUGGING
Drawing material: Stainless steel wire, alloy wire
Inlet wire: Φ 0.5mm-Φ 0.25mm
Outlet wire: Φ 0.15mm-Φ 0.05mm
Maximum modulus: 15
Drawing method: Horizontal four-cone pulley method
Maximum Line Speed: 800m/min
Control system: PLC Dual inverter control
M/C slip ratio: 16%
Capstan slip ratio: 12%
Cone Pulley: Mold steel vacuum quenching treatment
Max. Dia. Of capstan: Φ 120mm
Dia. Of Fix Speed capstan: Φ 174mm
Max. Amount of load wire: 16kg
Main engine power: 2.2kw
Take-up engine power: 1.1kw
Traverse power: 90W
Take-up bobbins: Φ 250mm
18. Transmission: Synchronous belt, flat belt
19. Brake: 5kg Electromagnetic Brake
Features:
Safe in operation, low in noise and high in efficiency Products from our machines have different configurations, which makes us in the leading position of concerning the product characteristics for users.
Jiangyin Xiangle Machinery Manufacturing Co., Ltd. Has established itself as one of China's leading names in the field of Wire Drawing Machines, Annealing Furnace, and other related accessories with our promise of quality products that stay ahead of time.
Our main products are series stainless steel wire drawing machines, Spring wire drawing machine, annealing machine lines, take-up machines, copper wire drawing machine and other related equipments. We believe that perfect high-quality products only come from zero defect production process. We have adopted the advanced production equipment and technology, scientific & standardized management system and strict testing standards to ensure international advanced level on quality, structure, performance and appearance.
Our Management Concept
Quality is the life: To perfect quality is the continual goal of our company staffs all the time
Service is the key: To provide satisfying service is our responsibility.
Innovation is the power: Holding the concept of technology and innovation, we will try our best to develop new product.
Integrity is the principle: Seek truth from fact, manage company with good faith.
We make each component with all our mind and energy; Meet multiple requirements all from clients' interests. We hope to create mutual benefit with our clients!
Your choice, we care! . Please feel free to contact us for further information.
