20L Bottle Blower Machine
5gallons PET Bottle Blowing/Moulding Machine/Bottle blower
moulding machine(also named blowing machine, PET bottle blower)
Application: 5gallons pet bottle/bucket/jar etc.
Configuration: Simens PLC, solenoid valve, international famous electric components.
Characteristic:
1. PLC intellectualized controlling
2. Revolving infrared heat oven; Preform heated quickly and evenly
3. Accurate and steady forming
4. Easily changed to produce hot filling bottle
| Main parameter: |
| Model | KM-12 |
| Container | Product material | PET |
| Volume | 10L-25L(3-5Gallon) |
| Theoretical output | 90-180PCS/H |
| Preform length | 15mm-460mm |
| Preform inner diameter | φ5mm-200mm |
| Moulding | Max.mould plate Dimenstion(L x W) | 420x500mm |
| Max.mould thickness | 400mm |
| Clamping force | 330KN |
| Mould opening stroke | 380mm |
| Machine size and weight | Main machine (L x W x H) | 218*77*196cm |
| Main machine weight | 1000Kg |
| Heater (L x W x H) | 237*68*165cm |
| Heater weight | 380Kg |
| Power | 40kw |
Zhangjiagang King Machine Co., Ltd. is a group company located in Zhangjiagang city Nanfeng industrial town, we have more than 15years experiences on beverage machinery and plastic machines.
We devote ourselves to the development, research and production of plastic machine and liquid food and beverage packing and filling industry and automatic blow molding machine in China.
Our Main products including: Mineral water and purified water producing line. Carbonated beverage producing line. 3 gallons& 5gallons producing line. Flat and tube UHT device, and CIP system. All the products are sold well in every province and city of the whole country and also exported to about thirty countries and areas with strong technical force, advanced equipment, scientific management system and perfect after-sales service.
Our Main Products Likes:
1000-15000bph water productione line
1000-15000bph juice production complete line
1000-15000bph carbonated drink production line
1000-15000bph wine bottling line
1000-9000tin cans/hr
5gallon bottle filling line
Stand alone machines also available
Welcome Customers Visit Our Company.
