0.02-2L double station extrusion blow molding machine
Extruding system: Hard gear box + Delta inverter
Clamping system: Fixed two-way translation module structure
Die system: Storage die
Hydraulic system: Yuken hydraulic valve / oil pump + electric hydraulic proportion control
Circuit system: Mitsubishi PLC + man - and - computer interface + Temperature - controlled module
|
Max. Product Volume |
(L) |
2 |
|
Capacity(idle loop) |
(PC/h) |
700*2 |
|
Screw Diameter |
(mm) |
60 |
|
Screw L/D ratio |
(L/D) |
24-30 |
|
Screw driving power |
(KW) |
15-18.5 |
|
Screw heating power |
(KW) |
10.8-12 |
|
Plasticizing capacity |
(kg/h) |
60-68 |
|
Oil pump motor |
(KW) |
5.5 |
|
Clamping force |
(KN) |
35 |
|
Platen distance |
(mm) |
138-368 |
|
Max. Die diameter |
(mm) |
90 |
|
Central distance of bi-die |
(mm) |
130-150 |
|
Max. Die diameter (Bi-die) |
(mm) |
55 |
|
Central distance of three-die |
(mm) |
80-110 |
|
Max. Die diameter (Three-die) |
(mm) |
40 |
|
Central distance of four-die |
(mm) |
60-85 |
|
Max. Die diameter (four-die) |
(mm) |
25 |
|
The Average Consumption |
(kw /h) |
16.5 |
|
Blowing pressure |
(Mpa) |
0.6 |
|
Air consumption |
(M3/MIN) |
0.4 |
|
Cooling water pressure |
(Mpa) |
0.3 |
|
Water consumption |
(L/MIN) |
60 |
|
Size of machine |
(L*M*H)/m |
3.0*2.15*2.6 |
|
Weight of machine |
Ton |
6.5 |
|
Wuxi Dongxiang Plastic Industry Co., Ltd is located in beautiful coast of TAIHU Lake, famous city of south Jiangsu province---Wuxi. It is a professional plastic machine manufacture gathered with designing, developing, producing and selling. By many years of concentrated business and combined with the practical experience, we make our products gradually serialization and standardization.
Our products has been widely used by a lot of well-known enterprises in China and well sold in Southeast Asia, the Middle East, Central Asia, the United States, East Europe, South African and other countries and regions during these years entering into the market.
By professional teams and strict management, our company can produce kinds of plastic pipe extrusion line, plastic profile extrusion line(PVC panel, PVC skirting board, PVC edge banding etc. ), mixer, palletizing line, plastic extrusion mould and so on. At the same time in determined innovation and enterprising spirit of pioneering courage, we passed the CE certification and accreditation Switzer GSG.
Our company always take the Quality to win the trust of customers, service to win the market as operating motto and take keep hard working and stain excellent as enterprise concept to continue develop. In pursuit of prefect quality, we warmly welcome our new and old customers to come to visit.
