250L double-ring blow molding machine:
Which can produce single layer chemical and food plastic drum.
Which can produce max capacity is 250Liter
Which can adopt to process many materials: PE, PP, PVC, PC, PA, ABS, PETG, TPU, EVOH, TPE, PPE etc.
|
Machine Model |
Model |
unit |
LHB120N |
|
Max.Product Capacity |
Max capacity |
L |
250 |
|
Accumulator capacity |
|
kg |
9-13.5 |
|
Extruding System |
Screw Diameter |
mm |
120 |
|
Screw L/D Ratio |
|
25-30 |
|
Extruding Power |
Kw |
132 |
|
No. of Heaters |
|
5 |
|
Screw Heating Power |
Kw |
32 |
|
Die Head System |
HDPE Plasticising Capapcity |
Kg/Hr |
200-280 |
|
Accumulator Capapcity |
L |
20-25 |
|
Max. Die-pin Diameter |
mm |
500-620 |
|
Number of Heating Zone |
|
6 |
|
Clamping System |
Heating Power of Die Head |
Kw |
39 |
|
Clamping Force |
KN |
560-880 |
|
Platen Size |
mm |
1100*1100 |
|
Platen Opening Stroke |
mm |
600-1400 |
|
Max. Mould Size |
mm |
900*1400 |
|
Power |
Mould Thickness |
mm |
610-750 |
|
Total Power |
Kw |
168 |
|
Average Power Consumption |
Kw |
95 |
|
Air Pressure |
Mpa |
1 |
|
Air consumption |
m3/min |
1 |
|
Cooling Water Consumption |
bar |
3 |
|
Cooling Water Consumption |
m3/Hr |
3/6 |
|
Machine dimension |
M |
6.8*3.3*5.2 |
|
Machine Weight |
T |
35 |
Zhangjiagang Longhua Machinery Co., Ltd is located in the city of Zhangjiagang City which lies conveniently between Shanghai and Nanjing. This geographical position gives us excellent connections to local and international transportation infrastructures.
We are a specialized manufacturer of blow molding machines and injection molding machines and others. We offer 3 types of machines in 19 different series and 60 grades.
Adopting European technology and staffing qualified and professional technicians, we provide machines that make bottles, drums, cans, and oil tanks, etc. Ranging in size from 10 milli liters to 1, 000 liters and plastic pipe extrusion lines as well as waste plastic recycling & reprocessing lines.
Longhua machines are sold to USA, , Italy, Sweden, Spain, Philippines, Malaysia, Viet Nam, the United Arab Emirates, Syria, Egypt, Pakistan, Algeria, Ukraine, Poland, India, Mexico, Brazil, Bengal, Nigeria, South Africa, Russia and other foreign countries
To produce good characteristics, steady and durable, simple operation and favorable price of full auto hollow blowing moulding machine and other machines for our consumers is the aim for Longhua Machinery to working hard.
