2L blow machine
This machine is made up of plasticizing system, die head, clamping structrue, hydraulic system, electric system, pneumatic system and cooling system. "robot" and other accessories can be chosen by customers. Machine can be equipped with 1 to 4 die head. Production is suitable for packaging of cosmetics, petroleum, chemicals, food productions and so on.
Available material can be PP, PE, PETG, PVC...
Can be equipped with 1 to 4 die head
For production up to 2L
PLC touch screen make the operation easier and clearer
Imported components adopted
Offer two layor, three layor and visual stripe
Basic Parameter
|
Applicable Material
|
PE, PP....
|
Max. Product Volume
|
One die head for 2L
|
Dry Cycle
|
2000 pcs/h
|
Machine Size (L×W×H)
|
2.4×1.5×2 (M)
|
Machine Weight
|
2850KG
|
Total Power
|
23KW
|
Power Consumption
|
12.2KW/H
|
Plasticizing System
|
Specification
|
good plasticizing capability, high output, transducer adjust speed, collect temperature-control signals to prevent the screw from cold starting
|
Speed Reducer
|
hard-teeth, low noise & wear-resistant speed reducer
|
Machine Barrel Screw
|
50mm ,L/D=22, 38CrMoALA high quality nitrogen steel
|
Plasticizing
|
35Kg /H
|
Heating Zone
|
3 Zone Casting, aluminum heater
|
Heating Power
|
8.2KW
|
Extrusion Motor
|
three phase asynchronism motor (380V\50HZ),11KW
|
Cooling fan
|
3 zones 85W
|
Extrusion System
|
Specification
|
One head
|
Max. Dia. of Die Head
|
100mm
|
Heating Zone
|
3 zone heat coil of stainless steel
|
Heating Power
|
4.5 KW
|
Die Heat Huff
|
Pressure and capacity can be adjusted
|
Preform Adjustment
|
By manual
|
Open and Clamping System
|
Clamping Force
|
30KN
|
Mold Move Stroke
|
128~368mm
|
Platen Dimension
|
W×H:300×320mm,
|
Mold thickness range
|
140~200(mm)
|
Electric Control System
|
Specification
|
Standard PLC and colorful touch screen for blow molding machine
|
Touch Screen
|
Colorful touch screen, auto alarm, diagnose the system
|
Temperature Control
|
Self-regulation
|
Temperature Module
|
TaiwanI-7018RP automatic temperature module, digital
|
Action control
|
Japan Mitsubishi, programmable
|
Protection Function
|
Automatic alert and breakdown feedback double protection of mechanical apparatus
|
Hydraulic System
|
Specification
|
Proportion pressure controller changing direction quickly and softly
|
Oil pump motor
|
three phase a synchronism (380V\50HZ),5.5KW
|
Hydraulic pump
|
Vane pump
|
Hydraulic valve
|
imported hydraulic components
|
System pressure
|
100kg /CM 2
|
Pipes
|
Bilayerhigh pressureblast pipes
|
Cooling Mode
|
Water cool and oil cooler separately
|
Pneumatic System
|
Specification
|
imported famous brand pneumatic pressure
|
Air Pressure
|
0.7Mpa
|
Air Consumption
|
0.3M 3 /min
|
Cooling System
|
Specification
|
mold\barrel\oil box adopt independentcooling waterway
|
Cooling Medium
|
water
|
Water Consumption
|
30L /min
|
Water Pressure
|
0.2-0.6MPa
|
Parison controller system (Optional)
|
Specification
|
Parison programmer is used to control the thickness of the bottle in high precision, it is a optional system for blow molding machine.
Japan MOOG 100points can be adopt to the machine
|
