4gallon Water Bottle Blow Moulding Machine
| Price: |
US $ 30000-50000SET |
| Trade Terms: |
FOB,CFR,CIF |
| Min Order: |
1/Set |
| Pay Type: |
L/C,T/T,Paypal,Western Union |
4Gallon water bottle blow moulding machine
1. New design
2. Power saving
3. Investment cost saving
4. And high speed
Bottle blow molding/moulding machine(TCY901D)
D means double station
Y means two-way guide rail clamping structure
"1"means number of die-head
Bottle blow molding/moulding machine (Voltage: 380V/50Hz)
Machine images
|
Bottle blow molding/moulding machine |
|
Specifications |
|
STCY901D |
|
Material |
|
PE,PP,PVC,PA |
|
Max container capacity |
L |
20 |
|
Number of die |
set |
1 |
|
Output(dry Cycle) |
pc/hr |
300 |
|
Machine Dimension(L*W*H) |
M |
5.0*4.1*2.8 |
|
Weight |
Ton |
12.5 |
|
Clamping Unit |
|
|
|
Clamping force |
KN |
105 |
|
Platen opening stroke |
mm |
200-550 |
|
Platen size |
mm |
500*550 |
|
Max mould size(W*H) |
mm |
550*500-300*800 |
|
Mould thickness |
mm |
210-320 |
|
Power |
|
|
|
Max drive |
KW |
63.5 |
|
Total power |
KW |
92.4 |
|
Fan power for screw |
KW |
0.9 |
|
Air pressure |
Mpa |
1 |
|
Air consumption |
m³/min |
0.9 |
|
Average energy consumption |
KW |
35 |
|
Extruder unit |
|
|
|
Screw diameter |
mm |
90 |
|
Screw L/D ratio |
L/D |
25 |
|
Plasticising capacity |
Kg/hr |
140 |
|
Number of heating zone |
Zone |
4 |
|
Extruder heating power |
KW |
20 |
|
Extruder driving power |
KW |
45 |
|
Die-head |
|
|
|
Number of heating zone |
Zone |
3-5 |
|
Power of die heating |
KW |
7-9 |
|
Max die-pin diameter |
mm |
220 |
|
Center distance of double die |
mm |
240 |
|
Center distance of tetra-die |
mm |
120 |
| Prod Model: |
TCY901D |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Product Name: |
Water Bottle Blow Moulding Machine |
| Suitable Material: |
PE,PP,HDPE... |
| PLC Control: |
Mitsubishi From Japan |
| Automation: |
Automatic |
| Making Method Of Parison: |
Extrusion-Blow Molding |
| Computerized: |
Computerized |
| Raw Material: |
PP,PE,HDPE... |
| Certification: |
CE,SGS,ISO9001 |
