Home Mould Products 500 Ton Plastic Injection Machine (WMK-530)

500 Ton Plastic Injection Machine (WMK-530)

500 Ton Plastic Injection Machine (WMK-530)
Price: US $ 46000/Set
Trade Terms: FOB,CFR,CIF
Min Order: 1/Set
Pay Type: L/C,T/T

500 Ton Plastic Injection Machine (WMK-530)

We are professional plastic injection molding machine manufacturer for all kinds of production requirements, Clamping force from 50 to 1680T , injection weight from 50 to 10000g . with best price/ performance ration of any machine on the market.

Some of the important features:
  • Clamping system:  Faster response, stable and high rigidity
  • Injection system:    Accurate and flexible, lower rejection rate
  • Control system:      Computer and simple operation,molding data memory system
  • Power system:        Energy saving, high efficient and precise
  • Metal parts:              The thickness of our frame, metal plate and wallboard are thicker than other company.
Other Information
  • Ceramic heating loop: Uniform heating, better thermal insulation properties so good for production
  • Visiable lubrication system:  on time clean, avoid cast steel parts abrasion and broken.
  • Oil treasure: Filter of hydraulic oil,good for pump and valves
  • Long working life: Imported spare parts and updated version
  • Aftersales service: Professional & timely
  • Delivery time:30-60 days
  • Port of dispatch: Shanghai

  Unit WMK-530
Screw Diameter Mm 75 80 85 90
Screw L/D Ratio L/D 23 21.2 20 18.9
Short Size Cm3 1854 2110 2382 2670
Injection weight G 1687 1920 2167 2430
Injection Rate g/s 426 456 484 514
Plasticizing capacity g/s 54.2 59.3 60.3 68.5
Injection Pressure Mpa 191 168 149 133
Screw Speed Rpm 0-150
Clamp Force KN 5280
Space Between Tie Bars mm 810*810
Toggle Stroke mm 800
Max. Mold Height mm 850
Min. Mold Height mm 350
Ejector Stroke mm 210
Ejector Tonnage KN 158
Ejector Number P 17
Max. pump Pressure Mpa 16
Pump motor powder Kw 55
Heater Power Kw 27.4
Machine Dimension(L*W*H) M 8.1*2.2*2.6
Machine Weight T 22

Prod Model: WMK530
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Clamp Force: 5280kn
Pump Motor Powder: 55kw
Machine Dimension(L*W*H): 8.1*2.2*2.6m
Machine Weight: 22t
Automation: Automatic
Structure: Horizontal
Computerized: Computerized
Plastic Type: Thermoplastic
Type: Injection Molding
Our company supplys different kinds of products. High quality and favaroble price. We're pleased to get your Inquiry and we will come back to as soon as possible. We stick to the principle of "quality first, service first, continuous improvement and innovation to meet the customers" for the management and "zero defect, zero complaints" as the quality objective.
