Model AGF 6-Ampoule wire-drawing and Filling Sealing Machine is developed by lur technicians who referred to the same machine which inside outside the countries and complied with the actual production situation, so it is more suitable for the technological requirements of water and power jinjections. It features high capacity good quality. Stable operation, and so it is an ideal equipment for ampoule medicine production.
The upside is set of one hundred(100)stage laminar flow purifying device.
Supplied with a device which ensures that failure to fill with shortage of bottles.
Both liquefacient gas and oxygen(or industrial acetylene and oxygen)is adopted as filling burning gas, so that, the productivity is high.
Stand-rotation wire-drawing and sealing device is adopted, sealing quality is good.
Primary tiny-adjustment is adopted for filling, error is smaller in filling quantity.
Supplied with a buffer control unit in the bottle feeding opening in match with production flow.
We can supply G. M. P. Verification documents and give assistance for pass G. M. P. Verification.
Operating theory
Ampoules(bottles)in bulk are fed into passage for bottlefeeding by the conveying belt. The ampoules in group by 6 PC. Place in the dividing disk and fed into the stations of filling, wire-drawing and sealing, then filling and sealed under the protection of one hundred(100)stages laminar flow. Sealed ampoules is putted into the bottle feeding funnel intermittently by a bottle-pusher.
Major Technical Parameters
1. Power: 380V, 50Hz
2. Gross power of motor: 1.5kw
3. Coal gas comumption: 1.2m3/h
4. Oxygen comumption: 0.6m3/h
5. Speed control: 30-36r/min(stepless speed adjustment).
6. Weight: About 1400kg
7. Overall size(length*width*height): 2500*1200*2250
Operating procedure
Before starting up, washing the filling pump, sampling and test, the clarity must be accord with tahe standard specified by the pharmacopoeia.
Adjust the pump stroke with a fine-regulating bolt, until get the best stroke, then adjust the dosage with shrinking regulation switch, make it up to standard and without any dripping.
Set the fillter'position correctly in order to avoid it frictionate ampoule neck.
Before ignition, make sure that oxygen, nitrogen, liquefied, natural gas and the air for suction is enough. First, open the burning gas valve, then open the oxygen valve and adjust the valve to have fire properly. Before stop machine, should turn off the oxygen valve. After about a minute, close the gas to prevent the return fire burning down the tubes.
Produetive capapcity
Ampoul
1ml 11500piece/h
2ml 11500piece/h
5ml 10000piece/h
10ml 8000piece/h
20ml 6000piece/h
| Model | Main electromotor | Turning-Bottle Electromotor | Glass Pump | Brower electromotor | High-Efficence Filter | Counter |
| 1-2ml | JW7114 | JW5614 | 5ml | DF-2.24 | GK 484*484*100 | H7EC |
| 5ml | JW7114 | JW5614 | 20ml | DF-2.24 | GK 484*484*100 | H7EC |
| 10ml | 5ml | JW5614 | 20ml | DF-2.24 | GK 484*484*100 | H7EC |
| 20ml | 26mm 76mm | JW5614 | 50ml | DF-2.24 | GK 484*484*100 | H7EC |
