I. Technical parameter:
1. Output paper: Tissue paper;
2. Raw material: Waste paper;
3. Capacity: 0.8-1ton per day;
4. Net paper width: 900mm;
5. Output paper weight: 13-40G/M2;
6. Rail gauge: 1300mm;
7. Working speed: 40-100m/min;
8. Drive way: Alternating current, speed control, section drive;
II. Structure and characteristics:
Cylinder section: Dia1000mm× 1100mm stainless steel cylinder mould 1set, dia260mm× 1100mm couch roll 1set, coated by rubber, rubber shore hardness 38C± 2.
2. Dryer section: Dia1250mm× 1100mm cast iron alloy dyer can 1 set, dia300mm× 1100mm touch roll 1set, 1group scraper knife. Rubber shore hardness 90C± 2. Mechanical pressure device.
3. Paper cutting section: 787mm slitting machine1set.
4. Drive and control section: Alternating current, speed control, section drive
| NO. | Item | qty(set) |
| 1 | 787mm tissue paper machine. | 1 |
| 2 | exhaust hood of dryer can | 1 |
| 3 | dia500mm axial-flow ventilator | 1 |
| 4 | 1.5m3High consistency hydrapulper | 1 |
| 5 | 0.8m2 High frequency vibrating screen | 1 |
| 6 | dia250mm pulp refiner | 1 |
| 7 | dia500mm Thruster | 2 |
| 8 | Sand remover | 3 |
| 9 | Suction box | 1 |
| 10 | 25m3bleacher | 1 |
| 11 | 4 inch Pulp pump | 5 |
| 12 | Vertical mixer | 2 |
| 13 | 33roots vacuum pump | 1 |
| 14 | 787mm slitting machine | 1 |
| 15 | Electricity control cabinet (Siemens of China) | 1 |
| 16 | 0.5T boiler(burn coal) | 1 |
Packaging
1. Fixed all the movable parts with plastic films.
2. Polystyrene foam plate wrapped around.
3. Wrapped with tighted plastic films several circles.
4. Fixed machine on the fumigated plywood pallet with iron wire.
5. Wrapped with wooden board around and nailed on.
Shipments;
1 sea transportation is from qingdao seaports or other ports.
2 the delivery time is decided by your needed machines or machine parts. But it also follows your needs.
Perfect service :
1.we can supply technical consulting and feasibility report according to client's current condition ;
2. We can make detail design of workshop and whole factory ;
3.we supply complete installation and test machine ;
4.we train client's engineer and worker for free ;
5.we supply spare part with best price ;
Company Information
Zhengzhou Guangmao machinery manufacturing co.,ltd has developed into a much more competitive company since establishment in 1982. Our complete paper production line sells well in international market, such as Russia,Indonesia,Uzbekistan,Tajikistan,Nigeria,Uganda,Pakistan,Egypt,Bhutan,Fiji,
Brazil,Paraguay,Syria,Libya etc. We also establish good strategic cooperation with local distributor. Mainlymanufactures all kinds of paper machines, toilet paper production line, Kraft paper production line, copy/writing paper production line. We have 4 paper machine producing workshops and more than 110 workers and more than 20 engineers. Our factory total area is 20,000 square meters. We sincerely welcome clients from all over the world visit our factory, any requirement, please contact via email, we will reply you as the first priority.We have passed CE, SGS, ISO quality system certification and all manufacture processes are conducted by the standard strictly.
FAQ
1.Why we choose your company, what could you do for me?
We have established for 10 years and have the stable production experience.
We use the best steel to guarantee the products' quality
Warranty:we make our machines one year warranty.
We will always give you heart to heart service
We always speak with facts and quality
2. How we visit your factory and what will be the procedure?
Our company located in Zhengzhou city,Henan province, if you take plane, it needs about 2 hours from Guangzhou city, 1.5hours from shanghai city and 1 hour from Beijing.we will pick you up from airport as well as the train station. We will take you to see our machine running in our Chinese clients' paper mill. Welcome you and your team to visit us at any time!
3. Could your engineer teach and train our worker and stay in our factory for long time?
Yes, we have very large engineer installation team,they can train and teach your worker to operate paper machine,but you should pay them salary.
4. How much water, electricity should I prepare for producing 1 ton finished paper?
(1) Clean water: 5M3
(2) Electricity: 250kw/h
5. Which kind of chemical I should prepare:
(1) Deinking agent
(2) Dispersing agent
(3) Bleaching agent
6. How about your company orders?
(1)One set of paper machine line or part is supported by us
(2) If we have urgent needs, we'll do it for you
Zhengzhou guang mao machinery manufacturing Co., Ltd. is located in zhengzhou city, China. We are a leading and professional paper machine manufacturer in China.
We specialize in the manufacture of paper machines, paper processing machines and paper machine parts.
Our company has perfect service system. We have experienced engineer teams, who can supply perfect service during the whole deal, including technology consultation, civil work design, project evaluation; Installation and testing the whole production line; Training engineers and workers; Meanwhile, we also supply spare parts for long time and manufacture machines in accordance with customers' special requirements.
1. Following is main introduction of our company:
(1) total area of factory: 20, 000m2;
(2) total qty of workshop: 4;
(3) workers: 110 workers;
(4)engineer qty: 25 engineers;
2. Why you choose us?
(1) professional engineer team with 30years experience;
(2) we can supply you turn -key solution without any trouble;
(3) we have strict quality control system and ensure there is no unqualifiedly product;
(4) professional installation technician and clear technical training for your workers;
(5) strict recalling system: If any problem of machine, we will recall it and change a new one for free;
3. About shipment:
1. Sea transportation and rail way transportation is our main shipment way.
2 the delivery time is decided by your the machine model, we can also adjust delivery time according to your special requirement;
We hope to establish friendship and business relationship with friends from all over the world.
