Aluminum Parts Die Cast and Zinc Pressure Die Casting

Aluminum Parts Die Cast and Zinc Pressure Die Casting
Price: US $ 1.00/Piece
Trade Terms: FOB,CFR,CIF
Min Order: 1000/Piece
Pay Type: L/C,T/T,Paypal
Aluminum die casting accessory feature:
1, Process of aluminum die casting part: Die casting + complete machining + heat treatment + surface treatment
2, Aluminum die casting mold Material: 8407, H13, P20, etc. Aluminum die casting mold Design: According to Drawing or Sample.
3, Aluminum die casting accessory material:  ADC10, ADC12, A380, 383, B390 (YL117), YL112, YL104 or as customer's requirement.
4, Surface Treatment of aluminum die casting part: Chrome plating, sandblasting, painting, anodizing, powder coating, electrophoresis
5, Standard exporting package for aluminum die casting part, such as plywood box, plywood pallet, carton & bubble bags

6, Application range of aluminum die casting parts: Auto parts, motorcycle parts, pump parts, locomotive parts, machinery parts, lamp chimney.

Products:







Products application1Auto /Moto Parts
2Machinery Parts
3Lighting Components
4Hardware Accessories
5Electric Motor Products
6Agricultural Machinery
7Electrical  Appliances
8Tent Parts
9Camera Parts
10Furniture Hardware












COMPOSITION AND PROPERTIES OF ALUMINUM DIE CASTING ALLOYS
DESIGNATIONS AA NUMBER
FORMER NO.
COMPOSITION (in percent max. unless shown as range)

A360.0
A360.0

A380.0
A380.0

E380.0
-


383.0
-

B383.0
-

A413.0
A13

B390.0
390

384.0
384
Silicon9.0-10.07.5-9.57.5-9.59.5-11.59.5-11.511.0-13.016.0-18.010.5-12.0
Iron1.31.31.31.31.31.31.31.3
Copper0.63.0-4.03.0-4.02.0-3.02.0-3.01.04.0-5.03.0-4.5
Manganese0.350.500.500.500.500.350.500.50
Magnesium0.40-0.60.100.300.100.300.100.45-0.650.10
Nickel0.500.500.500.300.300.500.100.50
Zinc0.503.03.03.03.00.501.53.0
Tin0.150.350.350.150.150.150.200.35
Titanium------0.20-
Total others0.250.500.500.500.500.250.20 (0.10 ea.)0.50
AluminumBal.Bal.Bal.Bal.Bal.Bal.Bal.Bal.
PROPERTIES (see notes)
Ultimate tensile strength (ksi)46474745454240.548
Tensile yield strength (ksi)2423232222193524
Elongation (% in 2" G.L.)3.53.53.53.53.53.5
1.0 2.5
Hardness (HB)758080808012085
Shear strength (ksi)262727252529

Charpy impact strength (ft. lb.óunnotched)4.23.53.5

2.0

Fatigue strength (ksi) (limit @ 500 million cycles)182020191920
20
Density (lb./in. 3 )0.0950.0980.0980.0970.0970.0960.0990.098
Melting range ( o F) approx.1035-1105  1000-1100   1000-1100  960-1080  960-1080  1065-1080945-1200960-1080
Specific heat (Btu/lb. o F)0.23 0.230.230.23




Coefficient of thermal expansion (in./in./ o F)11.811.711.711.511.510.311.711.3
Thermal conductivity (Btu/fthr. o F)65.355.655.655.655.667.778.656
Electrical conductivity (% IACS)2931312323312523
Modulus of elasticity (10 6  psi)10.310.310.310.310.310.311.910.3

Prod Model: DC-A101-001
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Weight: 450g
Material No: ADC10, ADC12, A380, 383, B390 (Yl117), Yl112, Yl10
Mould Material: 8407, H13, P20, etc
Cavity: 1-1, 1-2, 1-4, 1-8
Equipment: 350 Ton -800 Ton
OEM/ODM: Available
Size: Custom
Packaging: Carton, Wood Carton
Lead Time: 5-20 Days
Material: Aluminum Alloy
Surface Preparation: Spray Coating
Qirui Metal and Plastic Co., Ltd. was established in Xiamen in 1998. Our factory produce strictly according to ISO9001: 2008 international quality system. We have the facilities and capabilities of stamping, deep drawing, Alu/Zinc casting, injection molding, AC/DC motor fabrication, CNC machining and so on, skilled personnel, over 15 years of production experience to consistently provide high quality parts or components that meet your exact specifications, also we have R&D department with 3D printer to facilitate prototype development and offer a comprehensive OEM/ODM service package including consulting, engineering, cost analysis, and manufacturing. for instance, ours' chocolate fountains, Belgium waffle makers and frying pans are very popular around the world.
In addition, making metal and plastic parts, commercial and household appliance, one lighting department has been set up to facilitate LED lighting components and LED lights development, especially indoor LED lighting as LED bulb, down light, spot light and panel light to meet the LED lighting marketing requirement.

Please call or e-mail us today to see what solutions we can provide your company or to find out how we can help you with your project!
