Auto Feeding Laser Roll to Roll Printing Label Cutting Machine(No need Mould)
Suitable for cutting woven label, printed label, leather label, paper label, adhesive label, multi-ply label (kiss-cutting), textile label, fabric label, roll label, ribbons, badges, embroidery label, embroidered goods, embroidered patches, embroidery patch, cloth logo, printed fabric, printed textile, etc.
GoldenLaser - Recognition Series Laser Solution For Labels, Film
Various particular optic Camera software
Camera software has various identified mode, cutting with featured point position, cutting with figure picking of design, cutting with mark point position. It can make different kinds of labels and designs recogntion, cutting.
1. Featured point positioning cutting mode
Suits for various medium-small labels cutting. It can establish template according to whole labels, parts of labels, or other featured point of labels, the cutting design is created by hand, without the influence of template, so as to cut very complcate designs accurately. If there were an error of camers position, the cutting effect hard any excursion in X, Y axis cutting, (landscape&lengthways orientation), this mode can move the cutting design to avoid error, it can identify the trademark with arbityary angle, or opposite faced labels.
2. Automatic cutting with figure picking mode
It suits for clear figure of labels or small labels cutitng. Cause it adopts figure picking mode, so it can cut with different distorted labels, avoid the error when making template, and also it can zoom up or dowm according to picking figure, no need to establish the template, decrease the operation procedure, enhance the working efficiency. It can identify different kind of labels, with arbitrary angle.
3. Mark point positioning mode
Suits for different kinds of labels cutting. Mark point for position, no matter the size and shape of labels, no limitation of label sequence, high speed cutting. After identification and position with Mark point, it can be accurate cutting with whole pieces of design.
ROLL TO ROLL GALVO LASER – Suitable for large quantity production/complicated pattern
|
Printing labels laser cutting application:
Film scoring
Printing labels kiss cutting
Cut-Through
Film Surface etching film
Drilling Display
Film cutting
Polyesters cutting
Polyimide cutting
Nylon cutting
Polymeric film cutting
|
Laser Cutting Advantages:
1,Non-touching heating processing;
2,Section smooth,fast,no deformation,no wear,no need mould;
3,High precise laser cutting;
4,Personalized cutting designs;
5,Low maintenance and operation cost;
6,Easy operation;
7,Creat incredible high add-ed value of your products;
8,No need to design mold for die cutting.
|
Specifications:
With 200W US CO2 RF Metal laer tube;
Roll to roll system for feeding and sliting;
With colour-recognition sensor to recognize printing;
140mm*140mm/210mm*210mm galvo view for option;
With laser beam size around 0.12mm to 0.25mm
Constant temperature water chiller;
Cutting speed up to 60 meters one minute.
|
Golden Laser is a professional manufacturer in middle and small power laser machines. Since founded in 1992, we persist in market-oriented principle and makes innovation in the field of laser cutting, laser engraving and trademark cutting, etc. We research and develop many laser equipments which are special for textile, leather, large-scale engraving, cloth cutting, embroidery cutting, jeans engraving, trademark cutting. The application area also covers the field of model, advertisement decoration, organic-glass processing, wood processing, paper processing, marble engraving, craftwork, etc. Our product ability has reached to thousands sets per year and become one of key enterprises of China optical valley in the laser application area.
Our members of R&D group all come from China Optic Valley and famous Universities. We have 30, 000 square meters plant and R&D center which are up to the international standard, and our equipment is of super quality. We set up more than ten branches and service point in China. Our products sell fast in more than thirty MID-east and European countries.
Golden Laser pays attention not only to products, but also to exploring potential market and sales channel. We persist in the management concept of 'High quality and professional spirit bring up strength and brand', and also we support China's national industry with our strong technology and brand.
