1. Steel of core & cavity: 2316
2. Mould base: S45C
3. Cavity of mould: 1*1
4. Mold gate way: Cold ruuner
5. Surface: Polishing
6. Cooling system: Enought cooling
7. Dimension: 2D/3D control, tolerance: 0.02mm
8. Mold life: 500k-1000k shots
9. Finish time for first sample: 45 days
Key Specifications/Special Features:
In order to make sure doff automatic and without any eject mark, must be arrange high Polish for this Plastic Hanger Injection molded. This rack choose PA material, then advice choose hard enough steel.
1. Customized designs, sizes and frames are accepted
2. Mould steel: 2316 forging for cor and cav, S45C for mould base (customized)
3. Mould treatment: Final treatment for cor and cav plates by vacuum queching to 30 to 38deg; (whole plates 0.3mm hardness)
4. Mould cavity: 1+1
5. Mould software: Choose UG for 3D design, AutoCAD for 2D drawing, mould flow for runner analyze
6. Mould size: 750 X 600mm (depends on client's machine upon changing mold size)
7. Mould fix machine: 380T on injection molding machine
8. Plastic material: PC/ABS (on normal choose ABS)
9. Mould cycle time: 32 seconds/shot (without cool water when test this mold)
10. Mould doff way: Automatic by ejectors and air spring (Hasco standard)
11. Mould lifespan (minimum): 1, 000, 000 shots
12. Mould base: Copy standard mold base
13. Mould gate way: Hot runner (customized)
14. Mould packing: Standard wooden case
15. Minimum mould order should be one set
16. Mould shipment will be arranged within seven days after confirm amples and received balance
17. After product, if needs long time stay, should put oil (butter mix benzene) on the cor and cav, slider's surface prevents rust, with free spare parts during mould minimum life and technical Aegis.
Features:
1) We can provide mold for various parts according to your requirements
2) We own CNC processing centers, CNC spark working machinery and various advanced mould tooling equipment. We also have established a CAD / CAM / CAE mould design and development center.
3) Our quality, price, after sale services are really competitive
4) Our range covers from eletrical accessory, auto parts, household appliance, computer accessory, medical appliance, car accessory, digital&security parts ect.
Material of Core & Cavity |
Cav. |
Mould Base |
Mould life(shots) |
Surface/Texture |
P20
718H
NAK80
2316
SAARSRAHL AG 1.2311 |
1*1 |
LKM
LKM (HASCO 50#)
DME |
300000
500, 000
1000, 1000 |
EDM
MOLDTECH
High Polish |
Machine |
Lead Time |
Special |
Advantage |
|
Advance CNC, EDM, W-cut |
45 Days |
Glossy Surface |
High Polish |
|
Products Details: |
|
|
|
|
Dimension (mm) |
Material |
Dimension control |
Tolerance |
|
|
|
2D/3D Device |
0.02mm |
|
YG-PM is the Professional Plastic Moulds Manufacturer in China, and have more than Ten years of experiences in Plastic Injection moulds for Home Appliances plastic parts, such as LCD covers, Washing Machine Accessories, Vacuum Collector Accessories and other many kinds of parts.
YG-PM export more than 80% of the moulds it made to Overseas Markets, mainly export to Korea, Sweden, Norway, France, Brazil^^
