Product Name: Plastic Machinery
Place of Origin: China
Brand: Sheng Mei
DESC.: PBS-305 Series Blow Molding Machine
Price terms: FOB Shenzhen
This kind of model is suitable for producing 15-400ml containers. Featuring fully-flash-free and highly efficient automatic long production runs. 5" monochrome LCD screen combined with human-machine interfacing control system and a proportional pressure hydraulic circuit. The entire machine functions and conditions can be monitored and set on the control cabinet, such as temperature setting, hydraulic setting, flow rate setting, and function setting, alarm display, and parison control etc. For user-friendly operations.
SM Model No.
|
Unit
|
PBS-305S-PE
|
PBS-305D-PE
|
PBS-305T-PE
|
Main Screw Diameter |
mm
|
40
|
40
|
40
|
Main Screw L/D ratio |
L/D
|
22/1
|
24/1
|
22/1
|
Frequency conversion motor |
HP
|
7.5
|
7.5
|
7.5
|
Screw rotating speed
|
r.p.m
|
15~65
|
15~65
|
15~55
|
Number of heaters
|
Zone
|
4
|
6
|
6
|
Heating capacity
|
KW
|
4
|
6
|
5.5
|
Extruding capacity per hour
|
kg/hr
|
18
|
18
|
14
|
Roll Outer Diameter
|
mm
|
40
|
35
|
25
|
Mold center distance
|
mm
|
/
|
85
|
75*75
|
Switch on/off mold imitation
|
Mm
|
60~230
|
60~230
|
60~230
|
Mold length
|
mm
|
100~230
|
100~230
|
100~230
|
Dry cycle per hour
|
Time / hr
|
1400
|
1350
|
1350
|
Pump driven motor
|
HP
|
5
|
5
|
5
|
Clamping force
|
Ton
|
2.8
|
2.2
|
2.3
|
Fuel tank capacity
|
Gallon
|
50
|
50
|
50
|
Pressure of air
|
Kg/cm 2
|
4~6
|
4~6
|
4~6
|
Air Consumption
|
HP
|
3
|
3
|
3
|
Min/Max diameter of product
|
mm
|
10~75
|
10~65
|
10~45
|
Weight of product
|
g
|
5~40
|
4~25
|
3~15
|
Product capacity
|
C.C.
|
15~400
|
15~160
|
10~100
|
Total power consumption
|
K w/ h
|
13
|
18
|
18
|
Net Weight
|
kg
|
1400
|
1400
|
1400
|
Gross Weight
|
kg
|
1900
|
1900
|
1900
|
Size
|
m
|
2.2*1.6*2.2
|
2.2*1.7*2.2
|
2.2*1.6*2.2
|
Volume
|
m
|
2.4*1.8*2.05
|
2.4*1.9*1.95
|
2.4*1.8*2.05
|
DONGGUAN SHENG MEI PLASTIC MACHINERY CO. Ltd. is a foreign business registered at Guangdong province, China, a highly reputed manufacturer of blow molding machines.
Its parent company KAI MEI PLASTIC MACHINERY CO. Having more than 20 years' experience and prestige in Taiwan, KAI MEI is in line with the specialized technological project and automated operating system, and consummate the complete work flow in product design, streamlining organization, modulization, sales and marketing, etc., which made us an important player as extrusion blow molding machine vendor for the plastic packaging industry. With reliable quality, high efficiency, rigorous quality control combined with excellent technological support, Kai Mei has sold over 4200 machines to 50 countries around the world over the past 29 years, and has won a high reputation worldwide.
Established in 1977, Kai Mei Plastic Machinery Co., Ltd. Started its first R&D project in the design and making of PBA Blow Molding machines for producing containers of small capacities from materials such as PE, and PVC. With our progress in R&D and product releases, we developed a wide range of machines from the light duty PBA Series producing 5ml containers, to the heavy duty PBLL Series producing 220 liters containers, are fully utilized by customers around the world. For years, Kai Mei takes the leading position in Taiwan 's blow molding machine industry and enjoys its goodwill globally. In view of China' s economic growth and the increasing special quality requirement in the local market, Kai Mei set up a factory in Dongguan, China in 1998 and it was SHENG MEI PLASTIC MACHINERY CO. Ltd. Of today.
SHENG MEI was completed and gone into operation formally in October of 1999, in addition to the support from our strong high-tech professionals, we have well-trained, skilled mechanical technicians, engineers, excellent marketing personnel, attendants and on-the-spot staff members to provide customers the finest machinery and the most favor able service for the lifespan of our business.
Sheng Mei will work hand-in-hand with our customers to build our common dream and a bright future.
