Blow Moulding Machine for Plastic Ball

Blow Moulding Machine for Plastic Ball
Price: US $ 20000/Piece
Trade Terms: FOB,CFR,CIF
Min Order: 1/Set
Pay Type: L/C,T/T,Paypal,Western Union
Blow Moulding Machine for Plastic Ball
Item description
A. Machine model: TCY60II-2D
B. Capacity: 1000-2000 bottle/hour
C. Suitable Ball size: 40-160mm
D. Ball material: PE/PP
E. Usage: For kids playing on the playground.
Technical Parameters

Specifications
TCY60II-2D series
Suitable Material
PE  PP  PVC  PA.
Max container capacityL3L
Number of die headsset2
Output(dry Cycle)pc/hr1500x2
Machine Dimension L×W×HM3.0x2.2x2.8
Total weighton5.5



Clamping Unit
TCY60II-2D series
Clamping forceKN40
Platen opening strokemm138-368
Platen sizemm338x450
Max mould size(W×H)mm400x400
Mould thicknessmm140-210



Power
TCY60II-2D series
Max driveKW20.5
Total powerKW33.9
Fan power for screwKW0.3
Air pressureMpa0.7
Air consumptionm³/min0.6
Average energy consumptionKW16.5



Extruder unit
TCY60II-2D series
Screw diametermm60
Screw L/D ratioL/D24
Plasticizing capacityKg/hr60
Number of heating zonezone3
Extruder heating powerKW8.8
Extruder driving powerKW15



Die head
TCY60II-2D series
Number of heating zonezone3^5
Power of die heatingKW4.6
Max die-pin diametermm30
Center distance of tetra-diemm60--85
Prod Model: TD-70II
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Production Name: Blow Moulding Machine for Plastic Ball
Usage: Blow Hollow Balls with Hole
Type: Extrusion Blow Molding Machine
Raw Material: HDPE
Making Method Of Parison: Extrusion-Blow Molding
Automation: Automatic
Computerized: Computerized
Zhangjiagang Sino-tech Machinery Co., Ltd. is a group company located in the beautiful seaport city of Zhangjiagang, which is near to Shanghai. We devote ourselves to the development, research and production of plastic machine, beverage equipments filling and packing industry and automatic blow molding machine with over 20 years'experience.
Now our equipments have been exported to USA, Canada, Mexico, Colombia, Brazil, Argentina, UK, France, Germany, Belgium, Russia, Saudi Arabia, UAE, Yemen, Iran, Oman, Syria, Jordan, Israel, Egypt, Japan, Philippines, Myanmar, and India etc...

For plastic machine: , Our main products include as follow

Big-mouth PVC pipe excluding production line
PE big-mouth for gas, water supply excluding production line
Plastic sheet or panel production lin
Plastic profile production line
Plastic granulating production line
Plastic recycling machine
PP-R pipe production line
Plastics extruder
High speed mixer, various plastic auxiliary machines

For beverage machine, our Main products include as follow
The capacity of 2000-- 40000 BPH for mineral water and purified water producing line.
The capacity of 2000-- 40000 BPH for hot filling, MID-temp filling, aseptic cold filling lines.
The capacity of 2000 -- 36000 BPH for carbonated beverage producing line.
The capacity of 300 -- 1200BBH 3 gallon, 5 gallon barrel filling line
The capacity of 1000 -- 12000BBH glass bottle beer filling line
The capacity of 2000 -- 25000BH ice pop, ice lolly filling production line
Various kinds of linear and rotary engine oil and edible oil filling line
All kinds of water treatment equipment.
PET perform injection and blowing-stretching machine.
Extrusion blow molding machine
Turn-key projects
Flat and tube UHT device, and CIP system.

SINO-TECH purpose is "keep developing to meet worldwide clients' demands. "

Welcome to visit our company. Thank you!
