+ Parameters
Specifications Units KAL80series
Material PE. PP. PVC. PA...
Max container capacity L 12
Number of die set 1.2.3.4
Output(Dry Cycle) PC/hr 600× 2
Machine dimension(L× W× H) M 3.8× 2.2× 2.7
Total weight ton 5.2
Clamping unit
Clamping Force KN 120
Platen opening stroke mm 280-660
Platen size mm 520× 540
Max mould size(W× H) mm 530× 520
Mould thickniss mm 210-350
Power
Max drive KW 45
Total power KW 62
Fan power for screw KW 0.14× 3
Air pressure MPA 0.6
Air consumption m³ /min 0.8
Average energy consumption KW 23
Extruder unit
Screw diameter mm 80
Screw L/D ratio L/D 24
Plasticsing capacity Kg/hr 130
Number of heating zone zone 4
Extruder heating power KW 8.8
Extruder driving power KW 30
Die-head
Number of heating zone Zone 4
Power of die heating KW 3
Max die pin diameter mm 230
Center distance of double die mm 240
Center distance of tri-die mm 160
Center distance of tetra-die mm 110
+ Basic Equipment
Clamping system Double station+High-percision guide+Large arm cylinder axle
Extruder unit Hard gear box+Inverter
Die system Control-incoming die with special steel
Hydraulic system Hydraulic valve, Seal parts and Proportional control
Control system Import PLC+Human-machine+PLC automatic temperture control model
1. Experience: Zhangjiagang City Kalsing Machinery Co., Ltd. is one modernized enterprice, which designs, manufactures and sell the Blow Molding Machine Energy. We have 118 modles of Automatic Blow Molding Machine and various kind of air ducts for automatic industy, water tank and more.
2. Good After Sales Service: Our company can provide installation and debugging, if need someone to go aboard, we will send our two engineers to installation and debugging, and be responsible for training operators for one to two weeks. The related cost is undertaken by foreign customer. ( Security period: One year)
3. Market: The company's products are exported to Britain, Australia, Greece, Poland, Belarus, South America, South Africa, Iran, India, Indonesia, Egypt, Syria, Ethiopia 45 countries.
