Suitable material PP, PE
Capacity(Max) liters 30
Extruding motor power Kw 37
Dry cycle time second 6
Total consumption Kg/hr 63.7
Average consumption Kg/hr 32.6
Extruding capacity Kg/hr 90 depends on HDPE5502
Weight of machine tons 11.5
Machine size(LxWxH) mm 4.2× 2.2× 3.3
Extruding unit
Screw diameter mm 80
Screw L/D 25
Screw material 38CrMoAlA
Screw treatment nitrogen treatment
Screw hardness HV≥ 800
Barrel material 38CrMoAlA
Barrel treatment nitrogen treatment
Barrel hardness HV≥ 900
Driving method inverter motor and hard-teeth face gear box
Driving power Kw 37
Rotate speed rpm 10~80
Plastisizing capacity Kg/hr 90
Temperature controlling method PLC module for temperature controlling from Japan
Heating method Al-casting heating ring with insulating layer and stainless steel cover
Temperature control pricision ± 0.5%
Heating Power Kw 3∮ 5.2
Heating zones 4
Cooling for barrel 4 blowers
Blower power w 120
Zhangjiagang Faygo Union Science Co., Ltd. was established in 1999. We engaged in plastic machinery, beverage machinery, air compressor and blow moulding machines, such as plastic pipe extrusion lines, corrugated/ spiral pipe extrusion lines, kinds of sheet production lines, plastic profile production lines, wide door panel production lines, plastic board production lines, plastic recycling machinery, water/ fruit juice/ tea/ gas containing beverage wahing, filling, and sealing production line, high/middle/normal pressure air compressor and blow moulding machine for different bottles.
We are committed to the operational principle of "high quality products, star grade service" in order to ensure complete customer satisfaction. Relying on our experienced R&D team, we have developed a good market base for our machinery and products.
In addition to our well-equipped facilities and excellent quality, we firmly believe that customer service is more important than sales. We offer our customers the best technical plans, superior products, and perfect after-sales service to provide total customer satisfaction.
Welcoming distributors and end-users around the world to cooperate with us, we look forward to receiving your detailed inquiries and get mutual benefit cooperation in the near future.
