Product Description
NAMEELBOW
MATERIALCr5Mo, 12Cr1MoV, 10CrMo910, 15CrMo, 12Cr2Mo1, A335P22, St45.8III, A10bB A234-WPB. A420-WPL6. A234-WP12. A234-WP11. A234-WP5. A403-WP304. A403-WP304L. A403-WP316. A403-WP316L.
SIZE1/2"-48", DN15-DN1200
PRESSURESch80-Sch160, XXS
STANDARDSISO. ANSI. JIS. DIN GB/T12459, GB/T13401, ASME B16.9, SH3408, SH3409, HG/T21635, HG/T21631, SY/T0501
USEPetroleum, chemical, power, gas, metallurgy, shipbuilding, construction, etc
Norminal Pipe Size
DN |
Outside Diameter at Bevel
D |
Center to End |
Center to Center |
Back to Faces |
45°Elbow H |
90°Elbow F |
180°Elbow P |
180°Elbow K |
series A |
series B |
Long Radius |
Long Radius |
short Radius |
Long Radius |
short Radius |
Long Radius |
short Radius |
15 |
21.3 |
18 |
16 |
38 |
-- |
76 |
-- |
48 |
-- |
20 |
26.9 |
25 |
16 |
38 |
-- |
76 |
-- |
51 |
-- |
25 |
33.7 |
32 |
16 |
38 |
25 |
76 |
51 |
56 |
41 |
32 |
42.4 |
38 |
20 |
48 |
32 |
95 |
64 |
70 |
52 |
40 |
48.3 |
45 |
24 |
57 |
38 |
114 |
76 |
83 |
62 |
50 |
60.3 |
57 |
32 |
76 |
51 |
152 |
102 |
106 |
81 |
65 |
76.1(73) |
76 |
40 |
95 |
64 |
191 |
127 |
132 |
100 |
80 |
88.9 |
89 |
47 |
114 |
76 |
229 |
152 |
159 |
121 |
90 |
101.6 |
-- |
55 |
133 |
89 |
267 |
178 |
184 |
140 |
100 |
114.6 |
108 |
63 |
152 |
102 |
305 |
203 |
210 |
159 |
125 |
139.7 |
133 |
79 |
190 |
127 |
381 |
254 |
262 |
197 |
150 |
168.3 |
159 |
95 |
229 |
152 |
457 |
305 |
313 |
237 |
200 |
219.1 |
219 |
126 |
305 |
203 |
610 |
406 |
414 |
313 |
250 |
273.0 |
273 |
158 |
381 |
254 |
762 |
508 |
518 |
391 |
300 |
323.9 |
325 |
189 |
457 |
305 |
914 |
610 |
619 |
467 |
350 |
355.6 |
377 |
221 |
533 |
356 |
1067 |
711 |
711 |
533 |
400 |
406.4 |
426 |
253 |
610 |
405 |
1219 |
813 |
813 |
610 |
450 |
457.0 |
478 |
284 |
686 |
457 |
1372 |
914 |
914 |
686 |
500 |
508.0 |
529 |
316 |
762 |
508 |
1524 |
1016 |
1016 |
762 |
