1. Specification
*Flute Diameter: D2-D20mm.
*Surface treatment: Without any coating
*Material: HSS / solid carbide.
*Hardness: HRC45, HRC52, HRC60& HRC65.
2. Application
*Suitable for copper, Cast Iron, Carbon steel, and Mould steel, Titanium Alloy, Tool steel, and Heat-treated steel Processing.
3. Main Features
Grain size carbon tungsten, high toughness, altin coating, high wear-resistance, special use for high speed cutting of CNC milling machine. Also can increase
The smoothness, reduce the rubbing coefficient, and improve the lathe efficiency, save more production time.
4. Customization On Client Demands
*Outside Diameter
*Shank Diameter
*Flute Length
*Overall Length
*Flute
Remarks:
*OEM is available
*Free sample can be sent.
5. Main Technical Parameters
|
Standard |
|
Outside Dia/DC |
Flute Length |
Overall Length |
Shank Dia |
Flute |
|
2 |
11 |
49 |
2 |
4 |
|
2.5 |
14 |
57 |
2.5 |
4 |
|
3 |
15 |
61 |
3 |
4 |
|
4 |
19 |
75 |
4 |
4 |
|
5 |
23 |
86 |
5 |
6 |
|
6 |
26 |
93 |
6 |
6 |
|
7 |
31 |
109 |
7 |
6 |
|
8 |
33 |
117 |
8 |
6 |
|
9 |
36 |
125 |
9 |
6 |
|
10 |
38 |
133 |
10 |
6 |
|
12 |
44 |
151 |
10 |
6 |
|
14 |
47 |
160 |
12.5 |
6 |
|
16 |
52 |
170 |
12.5 |
6 |
|
18 |
56 |
182 |
14 |
6 |
|
20 |
60 |
195 |
16 |
6 |
|
Long shank |
|
Outside Dia/DC |
Flute Length |
Overall Length |
Shank Dia |
Flute |
|
3 |
15 |
100 |
3 |
4 |
|
4 |
19 |
119 |
4 |
4 |
|
5 |
23 |
132 |
5 |
6 |
|
6 |
26 |
139 |
6 |
6 |
|
7 |
31 |
156 |
7 |
6 |
|
8 |
33 |
165 |
8 |
6 |
|
9 |
36 |
175 |
9 |
6 |
|
10 |
38 |
184 |
10 |
6 |
|
12 |
44 |
205 |
10 |
6 |
|
14 |
47 |
214 |
12.5 |
6 |
|
16 |
52 |
227 |
12.5 |
6 |
|
18 |
56 |
241 |
14 |
6 |
|
20 |
60 |
254 |
16 |
6 |
