Application:
For seal or connect of pipe/tub-e lines
Material:
304,304L,316,316L,carbon steel or other material on request
Standard:
ANSI,DIN,JIS,BS
Size:
DN15 (1/2") to DN5000 (200")
Type:
Threaded Flanges, Socket Welding Flanges, Blind Flanges, Other Flanges
Types' Specification
Welding neck
1, Preferred for high-pressure, subzero or elevated temperature
2, Hub is tapered and bored to match pipe's inside diameter so flow is not restricted, preventing turbulence and reducing erosion
3, Easily radiographed and provides excellent stress distribution
Slip-on
1, Not normally used in high-stress applications due to low hub and weld attachment
2, Silps over outside of pipe
3, Inside of flange welded at hub and end of pipe
Lap joint
1, Used where bolt alignment or access for cleaning is required
2, Similar to slip-on flange when used with lap joint stub end
3, Radius at intersection of flange face and bore to match lap joint stub end
Threaded
1, Used where welding would would be hazardous
2, Designed for low-pressure and non-cyclic applications
3, Bore is threaded to match pipe thread
4, Tapered to seal pipe and flanges
Socket welding
1, For small-diameter chemical processes, hydraulic and stream distribution lines
2, Similar to slip-on flange
3, Counter bore matches pipe bore, allowing unrestricted flow
4, Counter bore from hub side fits pipe's outer diameter - can insert pipe in socket with fillet weld at hub
Blind
1, Used to close ends of piping
2, Has no bore
3, Permits access to sealed lines
Other flanges
Orifice, Expander, Reducing, Lightweight, Studding Outlets, Long Weld Necks,Metric, Navy Drawings, Customer Drawings
Baoding JiangdashengyeTrade Co., Ltd is a production and trade in one company, located in Baoding Hi-tech Development District of Baoding city, Hebei province. The company was founded in 2000, covers an area of 30000 square meters. The company is a professional production of sand casting, die casting, investment casting, forging, plastic parts and other kinds of mechanical parts production factory. The enterprise has a advanced casting production line, various specifications of Numerical control lathe, Milling lathe and so on total 35 sets, 5 CNC Machine. All products are exported to American, Europe, Japan, Middle East and other countries.
Products to the maximum extent to meet customer requirements for product quality, has a good reputation in the industry. Our tenet is quality first, customer first for the purpose. The company has the industry's well-known engineer checks, strong technical force, is your trusted partner. Let customers feel at ease the use of our products is our aim. Welcome more new and old customers to establish long-term cooperative relationship with us. Thank you!
