Type: Square, Rectangular, Round, H-Beam, Plate
Material: SF-Cu, AgCu, Cu-Cr-Zr
Material | Chemical Composition | Mechanical Properties | Electric Conductivity (%IACS) |
Cu (%) | Others (%) | Tensile Strength σb(N/mm2) | Yield Strength σ0.2(N/mm2) | Elongation δ (%) | Hardness (HB) |
E-Cu | >99.90 |
| 200 | 40 | 40 | 45 | 98 |
SF-Cu | >99.85 | P0.015-0.040 | 240-310 | 190-250 | 25-10 | 80-95 | 85 |
CuAg | >99.50 | Ag0.08-0.12 | 240-310 | 200-225 | 16-10 | 110-125 | 95 |
Cu-Cr-Zr | >98.0 | Cr0.3-1.2 Zr0.08-0.3 | 375-445 | 280-355 | 20-13 | 115-130 | 80 |
Material | E-Cu, SF-Cu (DHP Cu), CuAg, Cu-Cr-Zr |
Design | Square, rectangular, round , plate, H beam |
Straight or curved |
Outer contour parallel |
Internal geometries: parallel, single tapered, double tapered, multi-tapered, parabolic tapered, convex tapered |
Size | Square: 80mm~500mm Arc Radius: 4000-17000mm Wall thickness:6-50mm Length: 700-1000mm
Rectangular: 100-500mm×650mm Arc Radius: 4000-17000mm Wall thickness:6-50mm Length: 700-1000mm
Round: 110-800mm Arc Radius: 5000-17000mm Wall thickness:10-50mm Length: 700-1000mm
H-beam: Intergrated stype Arc Radius: 6000-16500mm Wall thickness:12-50mm Length: 780-1000mm |
Coating | Coating material: Cr, Ni-Cr, Ni-Fe or Ni-co |
