CE Certificated Automatic Injection Bottle Blow Moulding Machine

CE Certificated Automatic Injection Bottle Blow Moulding Machine
Price: US $ 8000-158000/Set
Trade Terms: FOB,CFR,CIF
Min Order: 1/Set
Pay Type: L/C,T/T,Paypal,Western Union
ERUSUN-SA series blow moulding machine is the latest high output semi-automatic PET blow moulding machine. Comparing to the traditional machine design, thanks to new concept of automatic bottle discharging unit, the patented heating system and the preforms automatic loading design, The SA series blow molding machine requires less manpower and reducing the work intension for the operator. New SA series blow moulding machine holds the cavity of the blowing mold up to 6 cavities, the output reaches 1800BPH for 500ml water bottles. Compared to the output of normal manual blow moulding machine, this is an outstanding improvement in the PET Bottle blow molding industry.

M odelSA 4SA6
Number of Cavities4Cavity6Cavity
Clamping Force180KN300KN
Max Clamping Stroke350mm250mm
Bottom Moving Stroke60mm60mm
Max. Stretching Stroke380mm380mm
Theoretical Output2000BPH2800BPH
Max. area of mould base620*420mm750*420mm
Max. Mould Thickness190mm190mm
Space Between Tie Bars550*340mm670*340mm
Electrical system
Voltage Standard380v/3PH/50Hz or special order
Total power(Full Loaded)15KW18KW
Max l ength of preform180mm180mm
Diameter of preform15mm-40mm15mm-40mm
Container Volume0.1-2.5L0.1-1.0L
Diameter of neck finish15mm-45mm15mm-30mm
Container Diameter110mm70mm
Max. Height of container370mm250mm
Air system
High pressure Air compressor>1.2m /3.0MPax23 (0.5L)
Dimension & Weight
Blow molding machine1.9*0.88*1.8M
Net Weight1.3T
Prod Model: YLS-4cavity
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia
Model: 4cavity
Type: Extrusion Blow Molding Machine
Raw Material: PET
Making Method Of Parison: Extrusion-Blow Molding
Automation: Non-Automatic
Computerized: Computerized
Certification: QS
ZHANGJIAGANG ERUSUN MACHINERY Co., Ltd. is one of the leading providers of liquid packing solution, for drinking water, carbonated soft drinks, juice drink, tea drink, energy drink, milk drink, alcoholic beverages, beer, and edible oil, packed in plastic bottles, glass bottles, pop-top cans, cups, sachets, stand-up pouch and etc.

ERUSUN is in this business for over 10years, have installed our filling line in more than 30 countries and regions, such as Russia, Armenia, Ukraine, Uzbekistan, Kazakhstan, Kyrgyzstan, South Africa, Mexico, Peru, Singapore, Canada, Malaysia, Thailand, Indonesia, Vietnam, India, Pakistan, Iraq, Iran, Lebanon, Nigeria, Tanzania, Sudan, Kenya, and so on.

We offer flexible and reliable filling machines that are easily adaptable to market developments and future technology, supported by value-added services. We are committed to being an innovative, responsive and reliable partner, providing sustainable solutions for the beverage industry.

Cooperate with us to get a bright future together, Our Products, Your Industry!
