Ceramic Industry /Syrup Circular Plate Filter Press Machine
Features
1. PP or and glass fiber polypropylene material plate and frame
2. Plate and frame type, box type
3. no need power supply.
4. filter plate pressed by hoisting jack.
5. Opening filter plate manually
Plate and Cloth
The filter plate of this kind has two types: plate and frame type, box type.
1,The plate and frame type has filter plates frames as a filter unit. Filter cloth can be easily fixed.
It can find its application in products that need filter medium (filter paper, filter membrane and
settling plate).
2,Box type filter plate combines filter plates and filter frames. It has a strong structure strength.
In themiddle of the filter plate stands. Loading inlet with big bore diameter, little resistance and fast flow.
3. The filter plate is generally formed on its fist mould with polypropylene and glass fiber
polypropylene, after the process of the CNC machining center, the flatness of the filter plate is lower than 25µm which make sure excellent sealing when pressing, and without any leakage when feeding. The filtration speed improved 20%, density and intensity, anti-fatigue , anti-aging speed improved
one times.
Model |
Filtering
area
(m*m) |
Inner
dimension
of frames
(mm) |
cake
thickness
(mm) |
Volume
of filter
chambers
(L) |
numbers
of filter
plates
(PCS) |
numbers
of filter
frames
(PCS) |
filtering
press
(Mpa) |
machine
weight
(Kg) |
External
dimension
(L×W×H)
(mm) |
ground dimension (mm) |
L |
B |
D |
H |
C |
XAQ320-30UM |
1 |
320×320 |
30 |
15 |
4 |
|
0.8 |
490 |
1050×570
×660 |
850 |
200 |
570 |
455 |
310 |
2 |
31 |
9 |
528 |
1300×570
×660 |
1100 |
3 |
46 |
14 |
550 |
1550×570
×660 |
1350 |
BAQ320-30UB |
1 |
15 |
4 |
5 |
0.6 |
490 |
1120×570
×660 |
920 |
2 |
31 |
9 |
10 |
528 |
1420×570
×660 |
1220 |
3 |
46 |
14 |
15 |
550 |
1720×570
×660 |
