| Price: | US $ 30000/Set |
|---|---|
| Trade Terms: | FOB,CFR,CIF |
| Min Order: | 1/Set |
| Pay Type: | L/C,T/T |
| Some details of mould | ||
| Name | Description | |
| Mould Material | NAK80, S136, 2316, 2738, H13, 5CrNiMo, 718H, P20, 40Cr, 60#, 45# etc | |
| Product Material | PP, PE, PC, PA, PS, PU, PVC, PMMA, ABS etc | |
| Cavity No. | Single or multi | |
| System Of Runner | Hot runner, Cold runner, Pin-point gate, Submarine gate, etc | |
| Ejector Type | Ejector pin, Air gate, Ejector plate, Hydro-cylinder, etc | |
| Term Of Mould Production | 15days- 60days | |
| Guaranteed Number Of Cycles | 300, 000-3, 000, 000 closing | |
| Mould Design Software | Ug, Proe, Solidworks AotoCAD, Moldflow, ect | |
| Mould Produce Process | |||
| 1 | Product Design | Customer send us the product drawing directly or we draw the product according to the sample, then we send customer the product drawing to confirm | |
| 2 | Mould Design | We' ll start to design mould after the product drawing confirmed, then send customer the mould drawing to confirm | |
| 3 | Mould Making | The mould start to make after the mould drawing confirmed, the process include prepare steel, rough cut, finish machining, assembly etc | |
| 4 | Mould Test | we' ll test the mould after mould assembly, then we' ll send customer samples and video of mould test to confirm | |
| 5 | Final Process | The mould start to polish if the sample is ok, and make grain, nitridation or chroming if customer required | |
| 6 | Mould Test | We' ll test the mould again after polishing, then send customer the final sample and video of mould test to confirm | |
| 7 | Mould Packing | The mould stard to pack with wooden case after the final sample confirmed, then the mould will be sent to port and waiting for shipping | |
| Prod Model: | LY-5028 |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Mould Material: | P20 |
| Product Material: | PE |
| Mould Base Material: | Lkm, Hasco |
| Shaping Mode: | Injection Mould |
| Process Combination Type: | Single-Process Mode |
| Application: | Commodity |
| Runner: | Hot/Cold |
| Installation: | Fixed on Injection Machine |
