China manufacturer Ceramic gold pvd coating machine/mosaic tile decorative pvd coating
The China manufacturer Ceramic gold pvd coating machine/mosaic tile decorative pvd coating suitable for coating all ceramic, porcelain, glass mosaic, mosaic tiles, also suitable for ceramic tablware and other metal products.
This is a ion coating machine of efficiency, harmless and pollution-free. It has the features of fast deposition rate, great ionization rate, big ion energy, easy operation, low cost, large productive capacity, etc.
Characteristic: The principle of the electric arc is integrating cold cathode arc discharge self-sustained light unite pulse technique and magnetron sputtering technology, thinning the particles to improve the properties of the film. It can coat on the surface of the metal as well as nonmetal.
Applied industry: It can be used to coat metal film, titanium nitride, titanium carbide, and zirconium nitride, chromium nitride and titanium, nickel, chromium, copper, and other compounds film, multi-layer super-hard film, nitrogen-doped titanium film and the alloy film, and in a very short time to complete all the machining process, it is a highly efficient multi-functional coating equipment.
This China manufacturer Ceramic gold pvd coating machine/mosaic tile decorative pvd coatingis extensively used in the fields of ultra-hard coating about the tools and mould, decorative coating about car wheels, ceramics, golf, watches making, hotel product, sanitary ware, luminaires, optical frame, hardware, etc.
We can design the dimension of the vacuum chamber according to your requirements. We can also design and configure the vacuum unit and electric controlling system according to your requirement.
We developed a complete after-sales system and effective service measures. Company now owns a professional after-sales service team with more than ten experienced engineers.
A special after-sales service hotline is set up to provide the customers with satisfactory problem solutions and technical support.
ISO 9001 standard to ensure the quality can meet the customer's requirements.
Technical parameter:
Mode
Dimension | LH-900 | LH-1100 | LH-1250 | LH-1600 | LH-1800 |
| 900*1000mm | 1100*1000mm | 1250*1500mm | 1600*1800mm | 1800*1800mm |
| Maily application | Metal decorative coating and Ceramic decorative coating |
| Coating mode and main confirguration | Eight multi-arc targets | Ten multi-arc targets | Twelve multi-arc targets | Twenty multi-arc targets | Twenty two multi-arc targets |
| Power source | Electric-arc power, Filament power, |
| Process gas control | Mass flowmeter + Electromagnetic ceramic valve |
| Vacuum chamber structure | Vertical side opening door, pump system postposition, double water cooling |
| Vacuum system | Molecule pump +Roots pump +Mechanical pump(8.0*10 -5 Pa)
Diffusion pump +Roots pump +Mechanical pump(8.0*10 -4 Pa) |
| Workpiece motion mode | Public rotation Frequency control: 0-20 rotation per minute |
| Measure mode | Number display composite vacuum gauge: from atmosphere to 1.0*10 -5 Pa |
| Control mode | Manual/Automatic/PC/PLC + HMI/PC four choice of control mode |
| Remark | We can design the dimension of the equipment according to customer's special technique requirement. |
For more solutions and information, please contact with Kelly:
Mobile number: 008613650364433
