ApplicationMaterials: Most of Non-metallic materials, such as, ceramics, PVC, ABS, acrylic, plastic, bamboo, organic materials, epoxide resin, glass, wood, and paper, etc.
Field: Woodworks, gifts, electronic components, clothes, leather, paper, medicines, food and package, etc.
Advantages1, Superior quality CO2 laser beam, stable light and low failure rate
2, With the excellent servo motor, the high-speed scanning galvanometer is of high marking speed and precision.
3, Adopt industrial control computer, strong resisting disturbance capacity, assuring the long stable working.
4, Easy operation software, compatible for all formats from CorelDraw, Photoshop, AutoCAD, etc.
5, Reasonable whole structure design, better stability and higher reliability.
6, SYNRAD / COHERENT tube can be refilled, excellent performance, Max. 45000 hours' life without maintenance
7, Be applicable to flying marking production line.
Parameters | Unit | Data | Data |
Type |
| CKD-CMLB-30/50 | CKD-CMLB-100 |
Power | W | 30/50/100 | 30/50/100 |
Laser |
| CO2 laser | CO2 laser |
Laser Wavelength | nm | 1064 | 1064 |
Optional Marking Area | mm | 70*70/100*100/110*110/200*200/300*300 | 70*70/100*100/110*110/200*200/300*300 |
Marking Speed | mm/s | 7000 | 7000 |
Repeated Frequency of Laser | KHz | 1-20 | 1-20 |
Marking Type |
| Static Mark | Static Mark |
Minimum Line Width | mm | 0.02 | 0.02 |
Minimum Character | mm | 0.4 | 0.4 |
Controller (Software - EzCad) |
| JCZ from China | JCZ from China |
Life-span of Fiber Laser Module | h | 45000 | 45000 |
System Operation Environment |
| WindowsXP/2000/Windows 7-32/64bits | WindowsXP/2000/Windows 7-32/64bits |
Cooling Mode |
| Air cooling | Air cooling |
Temperature of Operation Environment | ºC | 15~35 | 15~35 |
Voltage |
| 220V/50HZ/1-PH or 110V/60HZ/1-PH | 220V/50HZ/1-PH or 110V/60HZ/1-PH |
Power Requirement | W | 12000 | 12000 |
Computer Requested |
| with desktop computer | with desktop computer |
Communication Interface |
| USB | USB |
Dimension (L*W*H) | mm | 1150*1050*1250 | 1500*1050*1350 |
Weight | Kg | 120 | 120 |
