. Usage:
The machine(Single Screw Extruder/Single Screw Plastic Extruder Machine (SJ Series)) is mainly used for extruding PE, PP-R, ABS and other thermoplastic plastics. It is equipped with relevant molds and auxiliary machinery to form a production line to produce all kinds of plastic products.
Characteristics:
The charging barrel heating and cooling:
It adopts air cooling system and ceramic belt type heater to precisely control the temperature. Only middle air flow can cool cupper heat radiation sheets which are specially designed and produce high thermal conductivity. It can ensure precise melt temperature. Its noise is very low.
High output:
The special shelter type screw stem can be used in high output extruding. The length 12D shelter ensures thermoplastic plastic plastics steadily plasticizing to make it get highest quality melt. The screw stem shelter designing can increase the extruding output.
| Item/ Model | XJY-150*400 | XJY-210*470 | XJY-330*743 | XJY-416*936 |
Screw diameter
(mm) | 150*400 | 210*470 | 330*743 | 416*936 |
Working length
Of screw (mm) | 810 | 1000 | 1206 | 1475 |
| Structure form | Single-head, double-cone, different distance, different depth, convergence form |
Screw RMP
(r/min) | 5---18 | 2.0---20 | 2.0---20 | 2.8---28 |
| Main reducer | Hard-tooth surface gear reducer |
Power of extruding motor
( kw) |
18.5 |
45 |
132 |
200 |
Diameter/length
Of roller (mm) |
360*720 |
400*800 |
450*1000 |
500*1100 |
Linear speed of
Roll (m/min) | 5----12 | 3---30 | 3.5---35 | 4.4----44 |
Thickness of sheeting rubber
(mm) | 3---10 | 3---10 | 3----10 | 3---10 |
Width of sheeting rubber
(mm) |
500 |
550 |
700 |
700 |
| Maximum hoisting distance of the upper roll |
40 |
60 |
200 |
200 |
Power of sheeting motor
(kw) | 11 | 37 | 132 | 200 |
| Reducer | Hard – tooth Surface reducer |
| Production capacity (rubber gravity at 1.15) | 2980 | 4500 | 9000 | 11000 |
| Overall dimensions (L*W*H) (mm) | 2500*3385*1725 | 3000*4000*2500 | 4000*5000*3000 | 4700*6000*3200 |
| Total weight (kg) | 7500 | 16000 | 32000 | 40000 |
The company owns powerful technical strength, advanced technics, the best design and strict quality guarantee system, which owns a high repution in China rubber machinery industry.
The main products are plate vulcanizing press, open rubber mixing mill, banbury intensive kneader, extruder, rubber and reclaimed rubber machinery, within the (outside) tires complete set of machinery.The products have been sold to more than 20 provinces and cities in China and have been exported to more than 10 countries and areas.All of the products are designed visually by three-dimension CAD design, quickly built module, limited element analysis, analogue action and interfering inspection.The combination of three-dimension CAD system and internet guarantees the synchronization with internatinal advanced technology.The combination of three-dimension CAD and CNC numeral process center realizes the transit from traditional manufacture to modern three-dimension manufacture.At the same time, the company keeps good contact with several universities and research institutes.
The company takes"To live by quality, To develop by reputation, To innovate by science and technology, To keep improving all the time"as managing ideas, and insists on the principle of "Quality is the first, Reputation is the?First, Client is the first" that will provide you the best service.
