Funcitions and Construction:
The series Extruders with appropriate screws, dies and other auxiliaries can directly convert thermoplastic especial UPVC powder into Pipe, plate sheet, film and profile, and also Provide with function of modifying and Pelletizing.
The extruders are derived by D. C motor with a thruster to steeples regulate. It is also equipped with the over-load protection and stoppage alarming system. The screw's core and the outside of barrel is cooled by circulation of oil, it include vacuum venting and forced feeding.
|
Main Technical parameter: |
|
Mode |
Screws
(mm) |
Effective length
(mm) |
Screws. speed
(r/min) |
Main motor power
(kw) |
Heating Power
(KW) |
Extrusion output
(kg/h) |
Weight
(kg) |
Centre height
(mm) |
|
SJSZ51 |
51/105 |
1070 |
2-32 |
18.5 |
12.1 |
50-150 |
2500 |
1000 |
|
SJSZ55 |
55/113 |
1200 |
1-40 |
30 |
18 |
60-180 |
2500 |
1000 |
|
SJSZ65 |
65/132 |
1440 |
1-35 |
37 |
24 |
60-300 |
3500 |
1000 |
|
SJSZ80 |
80/156 |
1800 |
1-37 |
55 |
35 |
100-400 |
4000 |
1000 |
|
SJSZ92 |
92/188 |
2500 |
1-33 |
90 |
50 |
200-800 |
5000 |
1100 |
|
