Products models B22 B24
Line speed Max2700m/min Max2700m/min
Inlet wire 0.4_1.2mm 0.4_1.2mm
Main motor Stepless transmission control with inverter
Finish dia 0.10_0.45mm 0.08_0.45mm
Spool capacity 20_80kg 20_80kg
Brake Electromegetic braking automatic wire broken or full beam stop
Eye die holder Adjustable in up-down and front-back direction
No. Of dies 22 24
Capstan Ten ceramic layer Eleven ceramic layer
Reduction rate 15% 13%
Power consumption 15_20kw 15_20kw
Dimension 2000*1800*1890 2000*1800*1890
Weight 2300kg 2300kg
Yancheng AIJIN electrical machinery Co., Ltd adheres to the company spirit of "scientific and technological innovation, more professional and stronger" and strives to make the advanced, efficient and easy operation machines. "AIJIN"brand will become an international famous brand with the development of your enterprise!
