DCC-280？cold chamber die casting machine？
1.？Easy？to handle
？
-？Completely？automatic？process？cycle？and？analysis？function
-？Permanent？process？monitoring？via？sensors
-？Extensive？security？installations
？
2.Excellent performance
-？High？efficiency？and？reduced？scrap
-？High？quality？casting？of？complex？and？large？parts
-？Extremely？stable？value？of？the？machine
-？Multi-shift？operation？possible
？3.Flexible
？-？Small？or？large？casting？clusters
-？Non-ferrous？metals？including zinc,？aluminium,？bronze？and？brass？alloys
-？Moulding？chamber？easily？adaptable？for？shell-,？sand-？and？block？moulds
？
？
We？are？engaged？in？offering？a？wide？gamut？of？Casting？Machine？with？market？leading？prices.？Our？products？are？widely？demanded？due？to？their？longer？functional？life,？high？efficiency？ and？its reliable.？These？are？applicable？in？various？production？industries？and？are？ highly？appreciated？by？our？clients.
？
？
1.Features and？applications of？DCC-280 Cold chamber die casting machine
？280T Cold die Casting Machine
Suitable for？aluminum,zinc and copper alloy
PLC and person-machine interface
4-rod pilot elastic framework for excellent rigidity
Proportional relief and flow control valves
PLC and person-machine interface
Efficiency: maximum injection rate over 6m/s
minimum boosting time less than 20ms
？
2.Specifications of？DCC-280 cold chamber die casting machine？？？
？
The cold chamber die casting machine is suitable for die casting of non-ferrous metal with？high melting point, such as aluminum, znic and copper. It is widely applied for die casting of fittings of automobile and motorcycle, and parts for instrument and meter, and household appliance hardware of daily necessities.
？
This die casting machine is equipped with programmable logic controller (PLC) and Graphics operation terminal (person-machine interface) that are imported from Japan. The simple operating interface and proportional relief and flow control valves ensure easy operation of parameter and program setup. Die locking adopts crank expanding structure, 4-rod pilot elastic framework and has excellent rigidity, Advanced double-loop and 4-steps hydraulic injecting system that is constant and effective; maximum injection rate over 6m/s and minimum boosting time less than 20ms. The machine is superior in performance, and offers reliable an somooth operations, it owns trouble diagnosis and shooting function, it is an advanced type of die casting machine within our xountry at present.
？
？3.？Parameters of？DCC-280 cold chamber die casting machine？？？？？？
SUBJECT
UNIT
？？
Die lock force
kN
2800
Size of moving platen (HXV)
mm
930X900
Inner space between bars(HXV)
mm
610X580
Thickness of die block(Min./Max.)
mm
280/680
Stroke of moving platen
mm
480
Ejection stroke
mm
110
Ejection force
kN
150
Injection force
kN
340
Injection stroke
mm
425
Diameter of shot sleeve？？
mm
50
60
70
Fluid metal dosage？per shot(AL)
kg
3.1
Injection pressure (Min.~Max.)
MPa
88-173
Max. projecting area of casting
cm2
318
Dry cycle
s
10
Pipe line pressure
MPa
13
Motor power
kW
18.5
Machine weight
kg
12500
Overall dimensions(LXWXH)
mm
6600X1700X2900
Shenzhen Weitenglong Technology Co., Ltd., a company renamed from its predecessor Hong Kong Weilong Machinery Limited established in 1989, is specialized in manufacturing precision adornment equipment, lure equipment, grommet machine, DCC series cold chamber die casting machine, die-casting machine, low pressure machine, vertical injection molding machine and electroplating equipment.
With more than 100 patented technologies, Weitenglong ranks fifth in the country as an equipment production enterprise in terms of R&D strengths. In addition, Weitenglong has Won extensive commendation from international market. Leveraging our extensive international presence, robust technical strengths and complete after-sale services and integrating research, development, manufacture, marketing and services, our marketing network is distributed around the world.
We invariably practice our "everage high technology for development and premium quality for survival" enterprise conception. In April 2011, Weitenglong organized an oath-making campaian to promote top-grade brand products. Based on this conception, we will destroy all products that fail to meet CE and RoHS standards. The purpose of this campaign is to get quality and service awareness deeply rooted in the heart of every employee and promote Weitenglong brand awareness. Ception. In April 2011, Weitnglong organized an oath-making campaign to promote top-grade brang products. Based on this conception, we will destroy all products that fail to meet CE and RoHS standards. The purpose of this campaign is to get quality and service awareness deeply rooted in the heart of every employee and promote Weitenglong brand awareness.
