Economic CNC Milling Machine(M400)
Sepecification:Items | Specification |
Dimension | 760*210mm |
T-solt | 14*3*63mm |
Load | 200Kg |
X-axis | 400mm |
Y-axis | 230mm |
Z-axis | 500mm |
Distance spindle-cross table | 110-610mm |
Distance spindle-column | 320mm |
Spindle speed | 8000/10000rpm |
Mpa | 0.6 |
Spindle servo motorpower | 2.2Kw |
Spindle motor torque | 27N.m |
Driving motor torque | 4N.m |
Milling feed | 5000mm/min |
Fast motion | 12000mm/min |
Coolant pump power | 120W |
Control model | SIEMENS 808D |
Flat screen | 7.2LCD flat screen |
Multi-axis feed controller | Three axis(x/y/z) |
Least command incremen | 0.001mm |
Least input incremen | 0.001mm |
Poistioning accuracy | ±0.012 |
Repeating accuracy | ±0.006 |
Net weight/Gross weight | 1150/1250kg |
Packing Size | 146*194*218mm |
Spindle taper | ISO30 |
Standard Configuration:Safety locks, lubrication, cooling box and crumb tray, operation indicator (red, yellow, green), work lights, air guns, tool set, manual set, eight knives.
Optional configuration:Vertical cutter bar BT30, quick-change chuck BT30, collet cutter bar BT30, taper shank adjustable sets BT30, end mill rod BT30, pneumatic screws, precision mold clamp, suits collets, CNC Indexing head (axis).
Company Profile:
Taian Crystal Machinery Co., Ltd., is a modern and high- tech company which is a professional manufacturer of CNC LATHE, CNC MILLING, CNC MACHINE CENTER . With 5,000sqm workshops and offices, we have more than 15 years experiences in cnc machine research and production.Our machines have been exported more than 40 countries.we welcome all customers and friends to come to our company!
Why Choose US
- Over 300 clients from more than 40 countries could tell you we are your realiable parter.
- We are professional cnc machine factory,our price could beat any competitors in china market .
- We supply professional solution to you based on your own process one by one.
- We accept custom configuration such as auto feed system,the 3rd axis,hydraulic chuck and tailstock and so on.
- We supply one years Warranty for whole machine and 3 years warranty for cnc system and servo motor.
- 7*24 hours Email or phone service.
Taian Crystal Machinery Co., Ltd., is a modern and high- tech company which is a professional manufacturer of CNC LATHE, CNC MILLING, CNC MACHINE CENTER. With 5, 000sqm workshops and offices, we have more than 15 years experiences in CNC machine research and production. Our machines have been exported more than 40 countries. We welcome all customers and friends to come to our company!
Regarding the technical force, we have the most professional research and development staff, who can meet all different requirements on technology and production.
For the sales, there are internal trade department and international trade department. They are all professional salespersons who can help you solve problems on purchase and technology related to the CNC tools and test machines. Our products are sold both at home and abroad, and they are very popular around the world. All of products have pass CE certification. Welcome to contact with us to make building! !
