EPE PVC PE Flat Sheet Mould Foaming Sheet Board Extrusion Lines

EPE PVC PE Flat Sheet Mould Foaming Sheet Board Extrusion Lines
Price: US $ 3000/Set
Trade Terms: FOB
Min Order: 1/Set
Pay Type: T/T
Common Sheet Dies

Upper lip fine adjustment system

Lower lip fixed, or adjustable

Restrictor bar for option

Various width adjust systems are optional

Heavy Gauge Sheet Dies

With 90° Restrictor bar

Upper die lip adjustment range max.: 11mm

Width adjustment system optional

Product thickness max.: 60mm
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Material: Steel
We provide varieties of Flat sheet dies

1. Maxiumum width is 8000mm;

2. Multi flow channel;

3. For thin sheet, thick sheet, hollow sheet, Rainbow sheets;

4. Melt pump;

5. Hydraulic Screen Changer;

6. Feedblcoks

Heavy Gauge Sheet Dies

With 90'restrictor bar

Upper die lip adjustment range max.: 11mm

Width adjustment system optional

Product thickness max.: 60mm

PVC Foam Sheet Dies

Application: Foam PVC building products, bathroom fixtures, poster boards etc.

Die structure: Special design for flow channel and multiple oil temperature control

Zones at DIP lips which stabilize the flow and calibrating area.

Updated design for PVC celuka dies: The lip exit is equipped with a unique water

Cooling system, to reduce foam density and make the surface harder.

Common Sheet Dies

Upper lip fine adjustment system

Lower lip fixed, or adjustable

Restrictor bar for option

Various width adjust systems are optional

PC Hollow Corrugated Dies

PC hollow corrugated sheet thickness: 4-20mm, wave height: 20-60mm

PP hollow corrugated sheet thickness: 2-12mm, wave height: 20-40mm

With restrictor bar, suitable for all kinds of PP raw materials

Fine adjustment system operates easily

Cast/ Coating/Laminating Film Dies

Die width: Tailor made up to 8000mm

Product thickness tolerance: 3%

Die lip radius: R0.05

Die lip surface finish: Up to R 0.01

Flow channel surface harden treatment by chromium plating. Plating thickness: 0.02-0.03mm

Hardness: HV900-1000

Roughness of flow channel: R 0.01-0.02

Film can be produced as thin as 0.5, at widths up to 8000 mm.

Our mission statement: Excellent quality, sound goodwill, and service. Satisfactory long-term unremitting efforts have resulted in extensive quick screen-changing units and multi-layer co-extrusion feed-block of various sizes and types are available. We have CAD/CAM designing and CNC machining, contributing to higher precision premium products of consistent quality products.

We are your trust worthy partner.
