Material PE. PP. PA. PVC^^
Max container capacity L 50
Number of die set Single
Capacity PC/hr 100
Machine dimension(L x W x H) m 4.8X1.9X3.8(34.6m3)
Total weight ton 8
Clamping unit KN 180
Platen force Mm 350-950
Platen opening stroke Mm 800x900
Max mould size(W x H) Mm 600x850
Mould thickness Mm 350-450
Max drive KW 22
Total power KW 75
Air pressure Mpa 0.8
Air consumption m3/min 0.8
Average energy consumption KW/hr 40
Screw diameter Mm Φ90
Screw L/D ration L/D 23: 1
Plasticising capacity Kg/hr 110
Number of heating zone zone 6
Extruder driving power KW 18
Number of heating zone KW 22
Power of dieheating heating KW 4
Max die-pin diameter mm 18
Center distance of double die L 310
Jiu Zhou Mold Plastic Packing Factory lies in Huangyan, Taizhou, Zhejiang _The town of mold in China, which is in the coast of the EastSea. The traffic is convenient here.
Our factory built in 1987. It is a professional designer and maker of mold and plastic extruding machines. Our high quantity is based on local good machine foundation. In the last twenty years, we whole factory keep in innovation and exploitation, and absorb the new technology and skills. Design and develop the "Jingzhou" series automatic plastic blowing and extrusion hollow molding machine. Supply kinds of plastic blowing containers from 5ML to 200L for you. Also we can design and make various equipments used for special purpose as the consumer demanded. Cover the trade: Petrochemical industry, medical packing, osmetics packing, automobile, sports, hardware & tools, etc...Range of product: All kinds of plastic of products, such as bottle, pot barrel, tool case and bag, in empty for chair, automobile plastics piece, etc...Suitable raw material: PE\PP\PVC\PA\PC\PS\ABS\EVA etc...In these years, our machines had gained a good reputation by masses of user in and abroad of China.
Jingzhou machine the honest, develop and strive for perfection as our theory-idea, we create ideal investment environment for you from technical assistance to use, a connected sequence system of maintenance. We seriously welcome you.
