Chemical liquid truck function features
Component: Automobile chassis of the second class, special chemical liquid transport tank, chemical
Pump, and other parts.
Tank material: Carbon steel lining rotational moulding or stainless steeel sheet.
Tank body shape: Oval, square-and-round, round
Chemical pump: Adopts high-quality special chemical liquid pump of domestic famous enterprises.
Function: Can be independent or branch warehouse, packing different chemicals and liquid food.
Others: Internal setting several plastic wave clapboard, roundly get through high pressure seal test,
High tank intensity, stable center of gravity.
CLW SERIES PRODUCT------ YOUR FRIST CHOICE IN CHINA
Chengli Special Automobile Co., Ltd is a professional manufacturer of all kinds of special truck and trailer as well as other special equipment.
LPG tank is our most advantage key products which rank Top 5 in China, excellent engineers and high-grade production equipment as well as stricted quality control system can ensure all the tank from us run very well with 10-20 years use life.
CLW main products:
1. Dump Truck / Tipper Truck
2. Fire Fighting Truck / Fire Truck / Fire Vehicle / Fire Engine
3. Truck with crane / Truck mounted crane
4. Oil Tank Truck / Fuel Tanker Truck
5. Water truck / Water Tank Truck / Water Sprinkler Truck
6. Concrete Mixer Truck
7. Van truck / Insulated truck/ Refrigeration truck
8. Fecal suction truck / Sewage suction truck,
9. Cement Powder Tank truck/ Bulk cement truck
10. High-altitude operation truck,
11. Self-loading garbage truck, garbage compactor truck, sealed garbage truck,
12. Semi Trailer ( flat bed trailer / skeleton trailer / dump semi trailer / side wall trailer / low bed trailer / van container trailer / warehouse trailer, etc. )
Product model
|
CLW5310GHY3
|
Chassis model
|
DFL1311A4
|
Vehicle
spec.
|
Overall dimensions(mm)
|
11990*2500*3900
|
Tank dimensions(mm)
| 9200*2400*1760 |
Weight(kg)
|
GVW
|
/
|
payload weight
|
/
|
curb weight
|
14870
|
Approach/departure angle(°)
|
25/10
|
Front/Rear overhang(mm)
|
1460/3030
|
Fuel type
|
Diesel
|
Fuel consumption(100km/L)
|
26
|
Max speed (km/h)
|
90
|
Engine
spec.
|
Model
|
L315 30
|
Displacement(cc)
|
8900
|
Horsepower(kw/ps)
|
231/310
|
Engine type
|
6 cylinder,in-line , turcharger and after cooled
|
Chassis
spec.
|
Drive style
|
8*4
|
Wheelbase(mm)
|
1950+4250+1300
|
Front tread(mm)
|
1940/1940
|
Rear tread(mm)
|
1860/1860
|
Front axle loading(T)
|
9
|
Rear axle loading(T)
| 13
|
Gearbox
|
9 speed
|
Brake
|
By air,with power assisted , pressure boost
|
Tyre spec.
|
10.00-20
|
Tyre nos.
|
12+1(spare part)
|
Equipment
|
1. Tank can be separated to several unattached small tanks to fill different fuels
2. Tank meterial: carbon steel,stainless steel,FRP etc. optional
3. Tank shape:roundless,quadrate,oval optional
4. Oil pump: self-priming pump,gear pump optional
5. Oil meter:single,double,Fiscal processor optional |
Chengli Special Automobile Co., Ltd is a company with a tradition of over 10 years in the engineering industry and has aggregated a wide experience in this field. The main strategic program is focused on the production of trailers, tankers, dump trucks and other special vehicles. The company currently employs 1100 people and enjoys strong growth. Its turnover in 2007 is USD66.5 million and in 2013 it reached USD213.7 million. Chengli now ranks top 3 in special vehicle in China. The company' S total area is 1230 acres and in 2013 its annual production ability will expand to 20, 000 units.
Chengli is customer orientated and manages its business processes with the dynamics, efficiency and reliability to reach high customer satisfaction ratings. The combination of modern technology and human oriental assures a strong and competitive position in both domestic and international market.
Chengli has set up 127 service centers throughout China to provide ready-service for its customers. Complete coverage of sales service greatly reduces the distance between Chengli and its customers. Anytime customers want, Chengli will be there with them.
Working with reliable local partners, Chengli now is a key player in North Africa (Algeria, Libya, and Egypt), East Africa (Tanzania, Kenya, Uganda and Malawi)West Africa (Nigeria, Ghana, and Senegal), Middle East (U. A. E, Saudi Arabia and Qatar) and South East Asia., and Senegal), Middle East (U. A. E, Saudi Arabia and Qatar) and South East Asia.
Our company is located in Suizhou City, Hubei Province, center of China, the special-purpose vehicle city of China. We welcome friends from all over the world to visit us!
