1. Control Unit: PLC programmable controller and touch panel. English parameter process setting, state monitoring and products counting are convenient and intuitionistic. PLC automatic temperature control model.
2. Hydraulic Unit: It adopts famous international brand hydraulic valve and seal, proportional control. And has features of high stationarity and reliability, accurate operation, long longevity, quick response and so on.
3. If customer need, we will do the installation and debugging, according to the place that machine use, but the customer should be ready for installation. The time of installment and adjustment will not be over 7 days. The foreign buyer should pay the piper of personnels sent to install and adjust machines by seller, including traveling expenses, board wages, bed fee and laborage. The laborage is 50 USD per person per day. The place of training centre will be negotiated by two sides.
|
I.Techical parameter |
|
|
Model |
YF-75A |
|
Suitable materials |
PE,PP… |
|
Theoretical Output |
Depend on bottle design |
1100pcs/h |
|
Max.product volume |
1cavity |
5L |
|
Die Head Amount |
Piece |
4 |
|
Work Station Amount |
Piece |
2 |
Extrusion Unit
|
Screw Diameter |
75mm |
|
Screw L/D Ratio |
25:1 L/D |
|
Screw Speed |
10-50 r/min |
|
Plasticizing Capacity |
60kg/h |
|
Mould Unit |
1Cavity 2 Set |
1 cavity 2 sets |
|
Max.Bottle Diameter |
80mm |
|
Mould Thickness |
70-130mm |
|
Mold Board Stroke |
130mm |
|
Clamping Force |
50KN |
|
Power Unit |
Electrical source |
220-380V,3phase 50-60Hz |
|
Heating Power |
11KW |
|
Motor |
18.5KW |
|
Average Energy Consumption |
20KW |
|
Air Pressure |
0.7MPa |
|
Machine Size |
L*W*H |
3400*1700*2150mm |
|
Machine Weight |
3500KG |
|
Auxiliary Equipments |
Low Pressure Air Compressor 1 set(requisite) |
1.0m³ /1.0Mpa/15kw |
|
crusher machine |
65 |
|
mixer machine |
200kg |
