Max. Product Volume(L)
2L
5L
25L
50L
Dry Cycle (PC/h) of Moulding Machine
900× 2
1000
600
450
Screw Diameter(mm)
60
60
80
90
Screw L/d Ratio (L/D)
22-30
22-30
22-30
22-30
Screw Drive Power (KW)
15-18.5
15-18.5
30-37
37-45
Screw Heating Capacity (KW)
5.04-6.7
5.04-6.7
6.2-8.2
7.3-9.1
No. Of Heating Zone (Zone)
3-4
3-4
3-4
4× 4
Output of HDPE (kg/h)
65-80
65-80
100-120
140-200
Output of PVC (kg/h)
70-85
70-85
Oil Pump Drive Power (KW)
5.5
7.5
22
30
Clamping Force (KN)
37
60
215
260-400
Mold Stroke (mm)
138-368
148-508
350-780
450-1000
Max. Size of Mold (mm)
300× 320
370× 390
550× 650
700× 950
Capacity (L) of Moulding Machine
4
6.6
Max. Die Diameter (mm)
90
145
300
350
Die Heat Capacity (3KW)
1.8
2.5
5.28
7.52
No. Of Heating Zone (Zone)
3
3
4
4
Central Distance of Bi-die (mm)
130
160
Max. Die Diameter (mm)
55
80
No. Of Heating Zone (Zone)
3
3
Heating Capacity (3KW)
2.3
2.68
Blowing Pressure (Mpa)
0.6
0.6
0.8
0.8
Air Volume (M3/Min)
0.4
0.4
0.8
1.0
Cooling Water Pressure (Mpa)
0.2-0.3
0.2-0.3
0.3
0.3
Water Consumption(L/min)
50
50
60
85
Size of Machine (m)
2.7× 1.66× 2.18
2.75× 1.77× 2.18
4.2× 2.2× 3.3
4.5× 2.5× 3.8
Weight of Machine (Ton)
4.2
6
11.5
12
Ruian E-Dynamic Machinery Co., Ltd. is a professional manufacturer and exporter engaged in different packing machines, plastic machines and printing machines.
As a large scale enterprise, we conduct production strictly conforming to the ISO9002 international quality system standards. Taking market demands as our guide, we keep continuous creation and renovation and have won a good reputation in the packaging industry and related industries with high quality and good services. Our products sell well throughout the domestic market and are exported to Southeast Asia, East Europe, the Middle East, Africa and South American.
Adhering to the principle of Create brand on quality, establish credit on good services, we sincerely welcome clients from home and abroad, old and new to contact us for mutual benefits.
