Price: US $ 90-500/Piece
Trade Terms: FOB,CFR,CIF
Min Order: 1/Piece
Pay Type: L/C,T/T,D/P,Paypal,Western Union
Why rapid prototyping
Prototypes allow the design team to test for functionality and ensure design and fit is correct.
The prototypes can be used for sales meetings, customer presentations, and tradeshows overall time-to-market can be reduced since accuracy in design assures a streamlined project timeline.


CNC Prototypes Advantage
1. Machine many materials that is economically available to choosing.
2. Typical accuracy is +/-0.1mm. Ability to hold tight tolerances and high precision.
3. The cost be cheaper than even SLA, SLS, FDM rapid prototypes depending on the geometry.
Silicone Mould & Small batch producion
Silicone mould can be produced from the master made by the RP. After finished the CNC sample, Be sanded and polished to the Surface finished required of the part, than in turn to make the Rapid silicone mould.
Its application is mainly to produce plastics in small batch by vacuum and gravity casting method. The materials normally used are PU Epoxy. The batch size is from several pieces to over hundreds.
Color matched to Pantone or supplied sample.
Silicone: Dow Corning T4 from USA
Resins: ABS resin, PP resin, Nylon resin, Rubber resin, PMMA resins, POM resin

Silicone Mold Advantage:
1. Fast tooling, normal 1 to 2 days to complete the mould.
2. Fine details can be copied
3. Easy to release parts from the mould due to the non-stick property of the silicone rubber.
4. Good surface finish.
Finishing service
We operates a full finishing painting and texturing service.
Prototypes can be dressed in accordance with customer requirements.
Prototyping SolutionMaterialTolerance
 Computer Numerical Control (CNC) Any material that is commercially available in stock sizes.  A wide variety of plastic and metal material options.ABS,PMMA,POM,PP,PU,PC,PA66,PMMA,PVC,PVE, aluminum Zinc alloy, copper, iron, steel. +/- 0.005"
 Fused Deposition Modeling (FDM) production-quality ABS, ABS-M30 Polycarbonate PC-ABS PC-ISOULTEM, & PPSF +/- 0.002"
 Low Volume production(Silicone Mould /vacuum casting) ABS,PP,PC,PMMA,POM,Nylon ,PU and so on+/- 0.003"
Precision low volume production(injection molding)ABS,PMMA,POM,PP,PU,PC,PA66,PMMA,PVC,PVE,+/- 0.001"
 Metal prototypes(CNC,EDM,Drilling, Milling) Aluminum, Stainless Steel, Carbon Steel, 17-7 PH, Brass, Phosphor Bronze, Copper, Nickel Alloys, Beryllium Copper,metal and plastic rapid prototype +/-0.005"
Stereolithography (SLA) Technician's Choice, Semi-Flexible, PE-Like  Durable, PP-Like,ABS-Like  High-Impact ABS-Like Rigid, PC-Like High-Temp ABS-Like  High Resolution  +/- 0.002"
 Selective Laser Sintering (SLS) Nylon, Glass-Filled Nylon, Flame Retardant Nylon and Durable Nylon.  +/- 0.005"
Layer Thickness: 0.
004".
3D PrintingABS or PLA. Fast to print the model within 1~2hours+/- 0.003"
Surface Treatment:




-          Can be painted in any color with silk LOGO
-          Semi-transparent & 100% transparent
-          Laser engraving marks on surfaces
-          Anodizing
-          Electroplating
-          Painting
-          Chrome plating
-          Powder coating (Sand blasted)
Proper for plastic and metal parts
Prod Model: LW-02410
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Application: Hardware
Installation: Semi Fixed
Shaping Mode: CNC Machining/ CNC Milling
Mould Cavity: Single or Multi Cavity
Process Combination Type: CNC Machining/ CNC Milling
Lead Well Technology Co., Ltd, is a precise and professional manufacturer which specialized in plastic and metal rapid prototyping, and are involved in product design, 3D scan, SLA rapid prototyping, CNC prototyping, sheet metal prototyping, Small batch prototype casting by silicone mold, surface treating including painting, silk printing, Electronic-plated. Our company had a plenty of advanced equipments such as the SLA machine, Large-sized computerized numberial control processing center precise carving machines, vacuum casting machines, CNC punching machine, folding machine, and laser engraving machine etc.

With the Effective experienced engineers, Quick Response to the quote Requests, Quality Parts & Prototype Guaranteed, Fast Turnaround Delivery, Awesome Customer Service, The good reputation had already obtained from our overseas clients.

Our goal is to be your premier and right choice for CNC machining shop in China. If you have any inquiry or idea that you would like to quote, dont hesitated to contact us.
