High Precision Milling and Drilling machine(ZX7550CW, ZX7550C, ZX7550, ZX7550W)
Main feature:
1. Uses standardized assemblies from the VH milling machine universal use as milling machines and drill press
2. Easily shiftable gear drive ensures power transmission without losses
3. With V-belt spindle drive and gear spindle drive
4. Head swivels into the horizontal level on both sided via crank and toothed gear, easy activation of manual micro-feed for the spindle quill
Standard accessories of High Precision Milling and Drilling machine:
Drill chuck, Mill chuck, Reduction sleeve, Machine vice, Wrench, Inner-hexagonal, Camlock, Wedge shifter, Spindle arbor, Horizontal millnig bilt, Operation manual, Quality certificate, Packing list.
Description of of High Precision Milling and Drilling machine:
ZX7550CW KNEE-TYPE MILLING AND DRILLING MACHINE is a multifunction drilling and milling machine, bed rigidity, movement stability, high accuracy.
Guide by quenching with good wear ability. Vertical milling, horizontal milling adopts gear drive, transmission of large torque. Longitudinal can be moved with machinery power feeder, reduce labor intensity and improve the machining accuracy and surface finish.
Guide by quenching with good wear ability. Milling head mounted on the front sliding arm, it can move back and forth, not only in the vertical plane of rotation about 45 degrees, but also turn 360 degrees in the bed with a good universal nature of the processing.
If installing appropriate attachments, this machine has many processing function, such as milling, drilling, boring, plane abrasion, etc. Operation expediently, performance reliably, applying to metal finishing and maintain of kinds of companys, especially tools, moulds, fastenerprocessing.
| High Precision Milling and Drilling machine | ZX7550 | ZX7550C | ZX7550W | ZX7550CW |
| Max.drilling dia (mm) | 50 | 50 | 50 | 50 |
| Max.horizontal milling dia (mm) | 100 | 100 | 100 | 100 |
| Max.vertical milling dia (mm) | 25 | 25 | 25 | 25 |
| Max.boring dia (mm) | 120 | 120 | 120 | 120 |
| Max.tapping dia | M16 | M16 | M16(Vertical) | M16 |
| Distance.spindle to table surface (mm) | 140-490 | 90-490 | 80-460 | 90-490 |
| Spindle speeds range (r.p.m) | 230-1825 | 115-1750 | 230-1825(Vertical)
80-1300(horizontal) | (Vertical)115-1750
(Horizontal)60-1350 |
| Spindle travel | 120 | 120 | 120 | 120 |
| Table size (mm) | 800×240 | 800×240 | 800x240 | 800×240 |
| Table travel (mm) | 400×230 | 400×230 | 400x230 | 400×230 |
| Overall dimensions (mm) | 1100×1100×2080 | 1100×1100×2080 | 1280×1100×2080 | 1280×1100×2080 |
| Motor (Kw) | 0.85/1.5 | 0.85/1.5 | 0.85/1.5(Vertical)
1.1(horizontal) | ( Vertical)0.85/
1.5 (horizontal)2.2 |
| N.W/G.W (Kg) | 610/770 | 610/770 | 700/880 | 850/1000 |
