Feature of Bottle Unscrambler
l Famous Mitsubishi brand PLC and Touch-screen Control Panel, easy operate, full-automatic working
l Output capacity adjustable
l Torque limit part is designed for the main motor reducer so as to protect the machinery if malfunctions occur.
l Two put-casts in one cycle ensure that every work location should be with one bottle, which enhances bottle output efficiency.
l The bottles are neck locked through the air conveyor so as to avoid overturn in delivery.
l Dilapidated bottles will be eliminated by a special device.
l A lock detector is equipped for alarming; when locked, the machine will automatically stop.
l A photoelectric switch is set for starting when there is no bottle and stopping when there are bottles.
l An oil pump will readily fill up the gears, bearings and the cams
l Maintenance doors and mould replacement door provided.
l Machine outer tank and Revolving tank and meet the bottle part are all stainless steel AISI304. Frame part adopts high-grade carbon jointing.
l Adopted famous Mitsubishi, Omron electric parts
| Model | LP-1 | LP-2 | LP-3 |
| Production capacity(bph) | 8000-12000 | 12000-18000 | 18000-30000 |
| The pressure of gas source(Mpa) | 0.7 | 0.7 | 0.7 |
| Gas Volume(m3/min) | 0.5 | 0.6 | 0.7 |
| Power(kw) | 2.2 | 4.4 | 5.5 |
| To adapt to bottle-type(mm) | Bottle Drive50-90,Bottles of high -150-290 |
| Dimensions(mm) | 2500*2660*2000 | 2650*3300*2200 | 3710*4660*2390 |
| Machine weight(kg) | 3500 | 4000 | 6000 |
