High quality Plastic pallet blow moulding machine
Good quality and best price can make your needs
It is a special machines used for producing products with High Molecular Weight High Density
Polyethylene (HMWHDPE) as the raw material, including oversize plastic wall panels, door panels, ocean buoys, safety barriers for highway, athletic equipments, and plastic products of recreational facilities. The machines is designed and manufactured in accordance with standards of similar machine models of Germany, and this machine model has the optimized performance price ratio in the world.
TDB160E is an accumulation and injection type extrusion blow molding machine which can produce plastic door panels and plastic desktop panels. It has reasonable structure and steady and reliable performance.
Item |
Code Item |
Standard Code |
Manual |
Note |
Capacity |
MaX |
1200L(MAX) |
|
|
Extruder
(Main extruder) |
Main screw |
φ120mm |
High efficiency of mixing |
|
Screw L/D |
32:1 |
|
|
Screw number |
2 |
|
|
Screw material |
|
38CrMoALA |
|
Max. Extruder consumption |
360*2=720KG/Hr |
For example: HMW HDPE, change with material density |
|
Twisting transition method |
Electrical machinery, Gear box, Leather belt transmission |
Hard gear surface decelerator |
|
Driving motor |
132*2=264KW |
|
|
Screw rotate speed |
5_60r/min |
|
|
Ahead/back adjusting |
Yes |
|
|
Up/down adjusting |
Yes |
|
|
Temperature control zone |
6*2 |
Japan MTSUBISHI module |
|
Heating power |
40x2=80KW |
Three-phase |
|
Cooling for blower |
5*2 |
|
|
Cooling function |
Yes |
Cooling water |
|
Clamping unit (Mold opening/closing unit) |
Structure |
Tie-barless |
Self-locking, linear guider type |
|
Clamping directions |
Ball rail |
clamping structure in high speed and high force, to achieve quality products |
|
Hydraulic of mold moving |
φ100×800mm |
2 |
|
Mold opening stroke |
400~2000mm |
|
|
Hydraulic of self-locking |
φ200×160mm |
4 |
|
Hydraulic of retaining ring |
φ200×50mm |
4 |
|
Stroke of side mold moving |
2900mm |
|
|
Hydraulic of bottom blowing |
φ80×400mm |
|
|
Pre-clip device |
Max 915mm |
|
|
Platen dimension |
1600*1800mm |
W*H |
|
Max. Mold dimension |
1600*1800mm |
W*H |
|
Clamping force |
2000KN |
|
|
Mold opening/closing stroke control |
Electronic ruler |
|
|
Light
Electric
Safety protect |
FOTEK |
Taiwan |
|
Die head |
Form |
Circle & single layer type |
Special for panel type products
External,easy to processing and craft adjustment
Using 100-point MOOG parison control |
|
Material |
|
38CrMoALA |
|
Accumulator volume |
65L |
HMW HDPE=48KG |
|
Die dimension s |
φ300~φ750 |
|
|
Heating method |
|
Stainless steel heating ring, precision + 1% |
|
Heating capacity |
90KW |
3-phase |
|
Temperature control zone |
6 |
|
|
Blow-air |
Yes |
adjustable |
|
Adjusting of parison thickness |
Yes |
Adjustable by MOOG 100-point |
|
Injecting stroke control |
|
Accumulator electronic ruler + limit switch |
|
Adjusting method of thickness |
Inner mold adjusting |
|
|
Injecting pressure |
75~140kg |
adjustable |
|
Max. Injecting speed |
1.6Kg/sec |
|
|
Bottom blowing |
Hydraulic stroke |
400mm |
|
|
Mechanical hand |
Running method |
Hydraulic drive motor |
|
|
|
Cylinder drive |
Cooling water |
|
Electric system |
Temperature control |
Temperature controller |
MITUSBISH |
|
Protection |
|
Grating joint control |
|
Movement control |
PLC |
MITUSBISH |
|
Operation interface |
Human-machine interface |
HITECH, Taiwan |
|
Time setting |
Touch screen |
|
|
Oil pressure system |
Energy accumulator |
Twelve |
|
|
Main motor |
26KW |
Lv.4 |
|
Movement control method |
Proportion pressure control |
0~999 |
|
Pressure of system |
14-16Mpa |
Design pressure:21Mpa |
|
Power of servo hydraulic pump |
5.5KW |
|
|
Others
|
Lubrication way |
|
Using butter |
|
Oil pressure cooling |
|
Cooling effect is achieved by oil pressure cooling |
|
Pressure of gas |
1.0Mpa |
|
|
Quantity of gas |
5.0m³/min |
|
|
Pressure of cooling water |
0.4Mpa |
|
|
Quantity of cooling water |
350L/min |
|
|
Gear box, hopper place, die dimension cooling |
|
Use separated cooling water circuit, insure cooling effect |
|
Overall dimension |
L×W×H |
11500×9000×6900mm |
|
Weight |
TON |
70T |
|
