The machine has two screw plates. The machine is use to rub the head of nail and screw press various billet threaded bolt and thread accuracy up to two .The machine is operation safety high efficiency and a automatic machine.
Quick Details
· Place of Origin: Hebei, China (Mainland)
· Brand Name: FENGTAI
· Model Number: FT-2001
· After-sales Service Provided: Engineers available to service machinery overseas
· Cold Heading Machine Speed:: 25-130 pcs/min
· Cold Heading Machine Operation:: Semi or Full Automatic
· Cold Heading Machine Color:: Blue or Custmerized
· Voltage:: 220/380/440v
· diameter:: 3- 25mm
· length:: 10-254mm
· station :: .three station and four station
| type | Thread rolling
diameter | Thread rolling length | Production
rate | Motor
power | Weight |
|
| Z25-4 | 2-4mm | 6-30mm | 90-110 piece/min | 1.1kw | 300kg |
|
| Z25-5 | 2-5mm | 5-60mm | 80-90 piece/min | 2.2kw | 1000kg |
|
| Z25-6 | 4-6mm | 6-60mm | 80-90 piece/min | 3kw | 1300kg |
|
Our Services
1. Guarantee : 12 months after commissioning.
2. Installation : Engineers available to service machinery overseas.
Wherever you are, fengtai has the experience, knowledge, and skills to meet your needs and satisfy your requirements.
Hebei Fengtai Automatic Equipment Sci-Tech Co., Ltd. Is one of most famous machine manufacturers in China. Our company was founded in 2013 year. Located in Raoyang County, Hebei Province, China, we are very close to Beijing and Shijiazhuang city, so the traffic is convenient, if you would like to visit our company
