Injection characteristics;
XRW Series Batelite Injection Molding Machine is a new pr-oduct researched & developed by our company of high efficiency, energy saving, precision and environmental-protecting, using inverter servo motor or variable pump as option configuation, the manufac-ture techniques and performance diametera are prior to the dome-stic machines in the same grade.
The whole machine improved the three-dimensional design, redu-ces the malfunction rate in the largest extent. Finite Element Anal-ysis in design of the whole machine insures low transfiguration and long using life. High-tech movement analysis software optimizing the toggles ensures speedy and stable operation for the machine.
Equipping with the high response various proportional pumps save 30%-50% electric consumption and 1/3 water. Using name brand sealing elements, imported high quality hydraulic pipeline and the latest design of pipeline optimization, insures stable operation and low noise. The specialized conputer has the function of online ma-nagement and temperature linear control. The humanistic multi-function can meet lots of requirements of the customers.
Horizontal structure:
1, Suits for full thermosetting insertfree products.
2, Realization of low cost and automatic production.
XRW-3200B |
Injection Unit |
Screw Diameter |
mm |
A |
B |
68 |
75 |
Shot Volume |
cm 3 |
1200 |
1258 |
Shot weight(PF) |
g |
1310 |
1510 |
Screw Speed |
rpm |
0-165 |
Injection Pressure |
Mpa |
166 |
143 |
Clamping System |
Clamping Force |
T |
320 |
Opening Stroke |
mm |
590 |
Space Between Tie Bars |
mm |
640*640 |
Max.Mold Height |
mm |
580 |
Min.Mold Height |
mm |
200 |
Ejection Stroke |
mm |
125 |
Ejection Force |
T |
7 |
Others |
Hydraulic System Pressure |
Mpa |
16 |
PumpMotor Power |
KW |
22 |
Overall Dimension |
m |
1.25*1.7*2.3 |
Machine Weight |
Ton |
12 |
