Horizontal Injection Molding Machine (XRW-500BMC)

Horizontal Injection Molding Machine (XRW-500BMC)
Price: Negotiable/Piece
Trade Terms: FOB
Min Order: 1/Piece
Pay Type: L/C,T/T
Our company supplys different kinds of products. High quality and favaroble price. We're pleased to get your Inquiry and we will come back to as soon as possible. We stick to the principle of "quality first, service first, continuous improvement and innovation to meet the customers" for the management and "zero defect, zero complaints" as the quality objective. To perfect our service, we provide the products with good quality at the reasonable price.

Characteristics of BMC, DMC, SMC special machines:
1, a, Improve the production efficiency.
B, Realize the several injections, and the effici-ency can be multiple increased by the locking system.
2, Reduce the production cost of the manufactures.
3, Increase the product quality and ensure the rate of the finished product.
4, Reduce the labor intensity of the operators.
5, Save raw materials, beautiful appearance and environment protection.
6, Easy removal of the materials, and save the time.
7, None damage of glass fiber structure of the PRO-duct, and guarantee the intensity of the product.
8, Realize the production of high content glass fiber product.
9, Safe, rapid and environmental protection equip-ment, guaranteed rate of the finished roduct, and improved efficiency.
XRW-500BMC
Injection Unit Screw Diameter mm A B
28 32
Shot Volume cm 3 63 82
Shot weight(BMC) g 130 169
Screw Speed rpm 0-220
Injection Pressure Mpa 170 130
Clamping System Clamping Force T 50
Opening Stroke mm 260
Space Between Tie Bars mm 280*260
Max.Mold Height mm 260
Min.Mold Height mm 40
Ejection Stroke mm 65
Ejection Force T 2
Others Hydraulic System Pressure Mpa 16

PumpMotor Power KW 7.5
Overall Dimension m 3.2*1.0*2.5
Machine Weight Ton 2
Prod Model: XRW-500BMC
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Shaping Mode: Injection Mould
Application: Hardware
Installation: Semi Fixed
Process Combination Type: Single-Process Mode
