HRC55 High Speed Carbide Corner Rauis Milling Cutters

HRC55 High Speed Carbide Corner Rauis Milling Cutters
Price: US $ 4.5-75/Piece
Trade Terms: FOB,CFR,CIF
Min Order: 5/Piece
Pay Type: L/C,T/T,Money Gram,Western Union
HRC55  Corner Radius Long Shank Carbide tool

Our carbide cutting tools for the medical fields including Orthodontics, Orthopedics, Catheters,
and Surgical instruments ;for the automotive parts and engines, motorcycles, snowmobiles,
and bicycle industries; for pattern and mold makers ;for general manufacturing in marine,
recreational and consumer products industries ;for the plastics industry , and for the woodworking
industry.

1. Raw Material
HRC45HRC55  HRC60HRC65
YG10XYG10.2 &WF25(Taiwan)K44 & K40Sandvik H10F
Grain Size:0.7um
Co:10 %
Flexural strength:3320N/mm2
Grain Size:0.6um
Co:10 %
Flexural strength:4000N/mm2
Grain Size:0.5um
Co:12 %
Flexural strength:4300N/mm2
Grain Size:0.4um
Co:12.5 %
Flexural strength:4300N/mm2
2. High quality Coating

AlTiN TiAINTiSiNNano
Hardness(HV)32002800360042(GPA)
Thickness(UM)2.5-32.5-3 33
Oxidation Temp(°)90080010001200
Friction Coeffient0.30.30.450.4
ColorBlackVioletCopperBlue

3. Made by  ANCA ,Walter Grinding Machine


4. Each end mill is inspected by Zoller measuring and inspected machine.


5. The following Specification for your refer, We also provide the OEM or ODM service
order numbercuttingFluteShankCornerA.0.L
dlDR CornerL
1×3×4D×R0.2×50L×4F134R0.250
1×3×4D×R0.3×50L×4F134R0.350
1.5×3×4D×R0.2×50L×4F1.544R0.250
1.5×3×4D×R0.3×50L×4F1.544R0.350
2×6×4D×R0.2×50L×4F264R0.250
2×6×4D×R0.3×50L×4F264R0.350
2.5×8×4D×R0.2×50L×4F2.564R0.250
2.5×8×4D×R0.5×50L×4F2.564R0.550
3×8×3D×R0.3×50L×4F383R0.350
3×8×3D×R0.5×50L×4F383R0.550
3×8×4D×R0.3×50L×4F384R0.350
3×8×4D×R0.5×50L×4F384R0.550
4×10×4D×R0.5×50L×4F4104R0.550
4×10×4D×R1.0×50L×4F4104R1.050
4×10×6D×R0.5×50L×4F4106R0.550
4×10×6D×R1.0×50L×4F4106R1.050
5×13×6D×R0.5×50L×4F5136R0.550
5×13×6D×R1.0×50L×4F5136R1.050
6×15×6D×R0.5×50L×4F6156R0.550
6×15×6D×R1.0×50L×4F6156R1.050
8×20×8D×R0.5×60L×4F8208R0.560
8×20×8D×R1.0×60L×4F8208R1.060
8×20×8D×R1.5×60L×4F8208R1.560
10×25×10D×R0.5×75L×4F102510R0.575
10×25×10D×R1.0×75L×4F102510R1.075
10×25×10D×R1.5×75L×4F102510R1.575
10×25×10D×R2.0×75L×4F102510R2.075
12×30×12D×R0.5×75L×4F123012R0.575
12×30×12D×R1.0×75L×4F123012R1.075
12×30×12D×R1.5×75L×4F123012R1.575
12×30×12D×R2.0×75L×4F123012R2.075

3×8×3D×R0.3×75L×4F383R0.375
3×8×3D×R0.5×75L×4F383R0.575
3×8×4D×R0.5×75L×4F384R0.575
3×8×4D×R1.0×75L×4F384R1.075
4×10×4D×R0.5×75L×4F4104R0.575
4×10×4D×R1.0×75L×4F4104R1.075
4×10×6D×R0.5×75L×4F4106R0.575
4×10×6D×R1.0×75L×4F4106R1.075
5×13×6D×R0.5×75L×4F5136R0.575
5×13×6D×R1.0×75L×4F5136R1.075
6×15×6D×R0.5×75L×4F6156R0.575
6×15×6D×R1.0×75L×4F6156R1.075
8×20×8D×R0.5×100L×4F8208R0.5100
8×20×8D×R1.0×100L×4F8208R1.0100
8×20×8D×R1.5×100L×4F8208R1.5100
10×25×10D×R0.5×100L×4F102510R0.5100
10×25×10D×R1.0×100L×4F102510R1.0100
10×25×10D×R1.5×100L×4F102510R1.5100
10×25×10D×R2.0×100L×4F102510R2.0100
12×30×12D×R0.5×100L×4F123012R0.5100
12×30×12D×R1.0×100L×4F123012R1.0100
12×30×12D×R1.5×100L×4F123012R1.5100
12×30×12D×R2.0×100L×4F123012R2.0100

6. Package and shipping details
Laser brand on the cutter's shank , 1 pc in a plastic tube , 10pcs a group
Delivery Time
For samples , we dispatch your tools in 2-7 workdays .
For formal orders,We delivery tools to you in 7-30 workdays , it will depond on your order quantity .

7. Payment Term
T/T ,Western Union , MoneyGram,L/C

8.Why Choose Hiboo Tools
Several years' professional producting and exporting experience
Advanced RD department meet your special demands
High precision CNC machines,high standard and strict inspection
Custom demand are welcomed ,OEM and ODM Service
All payment terms supported
Fast delivery time and Convenient Transportations
More than 2000 products are available
For your suggestions or complaints,We will handle them Soonest
Prod Model: corner raduis end mills
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Diameter: 1-20mm
Length: 50-100mm
Helix: 35 Degree
Hardness: HRC55
Coating: Tisin
Samples: Available
OEM: Accept
Work Piece: Steel,Stainless Steel,Cast Iron Ect
Process Usage: Metal-Cutting CNC Machine Tools
Movement Method: Point to Point Control
Control Method: Closed-Loop Control
Numerical Control: CNC/MNC
Performance Classification: High-End CNC Machine Tools
Processing Precision: 0.005
We located In Changzhou City, About 1 Hours from Shanghai, China. We has committed to manufacturing solid carbide end mills, Drills, reamers, Inserts, Both standard and Nonstandard tools, offering high quality cutting tools, competitive price and unequaled customer service.

Our carbide cutting tools For the medical fields including Orthodontics, Orthopedics, Catheters, and Surgical instruments; For the automotive parts and engines, motorcycles, snowmobiles, and bicycle industries; For pattern and mold makers; For general manufacturing in marine, recreational and consumer products industries; For the plastics industry, and For the woodworking industry.

Efficient workshop and 5AXIS grind machines run by skillful operators. We have our partners as complementarities sited around our factory in 5 Km who is product turning tools, holder And others, they are all around our factory in 5 Km. So, you can trust us that we must satisfy your needs.

We earned reputation of good quality, Fast producting, Delivery in time, reliable service. Hiboo will continue to introduce some new series of tools to meet different requirements. Sincerely Welcome to inquiry products and visit our company, thanks.
