| >>>The whole package by wood case include |
1 * Water Pump
1 * Smoke Pipe
1 * Main Body
1 * Air Pump
1 * Power Line
1 * Wrench
1 * Exhaust Fan
1 * Laser Tube
1 * CD
1 * Manual
1 * USB Cable
1 * Manual/Accessory Bag
Technical parameters |
| Tag arguments | Working area | 400 *300mm |
| Laser power | 40w/60w |
| Engraving/cutting speed | 100-300mm/min |
| Resolution ratio | 0.0125mm |
| Cutting thickness | 0-15mm |
| Minimum shaping character | Character 2x2mm ,Letter 1x1mm |
| Support graphic format | BMP,PLT,AI,CDR,DXF |
| System Environment | WINDOWS XP/Win7/8 |
| Software | moshi V2.0 |
| Supply Voltage | 110/220V±10% ,50/60Hz |
| Working table | Aluminum plate |
| Up and down size(optional) | 50mm |
| Laser characterization | Laser-type | Sealed CO2 laser tube |
| Laser power | 40w/60w |
| Wave length | 10.64um |
| Cooling Way | Water Cooling |
| Operating temperature | 5°C -35°C |
| Package | N.W | 51KG |
| Dimension (MM) | 980x680x280mm |
| Package size(MM) | 1080 x 780 x 320(standard plywood wooded case) |
| Model | Power | Working area(MM) | Dimension(MM) | Package size(mm) | N.W |
| AZ-2525 | 40W | 300x200 | 810x510x260mm | 1010 x610 x360 | 30Kg |
| AZ-4030 | 40W | 400×300 | 980x680x280mm | 1080 x 780 x 320 | 40kg |
>>>Product Features
This machine is designed mainly for stamp engraving, it is portable in size, so you can put it on table, thus save your space.
It is suitable for the new business starter in stamps and art works industry.
Because of the clear pictures engraving, it sells well in our local market, and believe that you will find a ready market either.
Beasides, it can also engrave on many other materials, such as wood, leather, glass, etc. and even on some metals.
It Can engrave on the rubber materials and Rubber sheet. Some of my customer country don't need rubber sheet, don't worry, it can cut and engrave on the rubber. It aslo can engrave on the acrylic, wood/ MDF/wood board/ leather/ leaf.. and other nonmetal materials.
Our factory has the 200x300mm working size. the samller one, fit for customer's different requirments. can do the rubber stamp work like the 400x400mm 40w/60w Co2 laser machine/
1),Mainly used for engraving of non-metal material: ox horns,wood,organic glass,atomic materials,crystal,bowlder, etc..
2),Applying for processing of small-width artistic products. For the engraving of patterns and
characters on double-color planks,wood board,bamboo piece,bracelet,organic glass plank and cloth.The patterns and characters engraved are real to life and pleasing to the eye.
3),For the engraving of titles,types,signs,patterns etc. on electronic parts, which will last for long time.
>>>FAQ:
Do you have any certificate?
All series of machines have passed CE verification.
What is the trade term?
Both FOB and CNF/CFR/CIF are accepted.
What is the payment terms?
We take 30% deposit and 70% balance should be paid before delivery by T/T.
West Union and PayPal are preferred for small amount.
How about the documents after shipment?
All original documents will be sent to client by DHL after shipping, including packing list, commercial invoice, B/L, and other certificates as required.
Do you arrange shipment for the machines?
We will arrange shipment for transactions based on FOB/CIF terms.
For EXW price, shipment should be made by clients or their agents.
>>>After-Sales Service&Warranty:
1.We provide one year free warranty beyond which we charge only accessory fee and cost;
2.Warranties on laser tubes differentiate due to brands diversities. Contact us to get exact warranty period on your purchase;
3.Get warranty extension with preferential price;
4. Free lifetime remote technique-service via telephone, email, online video, Skype, QQ etc.;
5.Free lifetime training and guidance in our factory;
6.Get operating software CD, U Disc for free;
>>>The following circumstances are exclusive:
Natural aging of consumables and other parts;
Man-made damage due to maloperation against the operation manual;
Malfunction and damage caused by repair, transform without permission;
Damage caused by fire, flood, voltage anomaly and other force majeure;
Other non-product quality damage.
If you need any help, please feel free to contact us. You will obtain quick response and excellent service!
Service Hotline: 400-888-9892
AOTOPTO Technology Co., Ltd. is a professional manufacture focusing on providing for medium or low power laser processing solutions for all users, combing R&D, manufacuture and sales in vertical integration in laser value chain. Based on the QC system, the whole series of regular types have been certificated by European CE certification.
Say good bye to the era of scissors and drill
Greeting the time of laser technology
Excellent and omnipotent performance in cutting and engraving
Utilizing the laser, rather than producing it
Marking cutting&engraving easier than ever before.
AOTOPTO Laser, a high-tech enterprise, is committed to providing laser power processing solutions for every kind of applications in different industries.
We have been specializing in export and service of various types of laser machinery.
LASER CUTTING MACHINE/ENGRAVING MACHINE
1. Laser cutting/engraving machines. Two Head laser cutting machines- AZ/AZ-D Series
2. Specially applied to acrylic or MDF cutting machines. AZ-L Series
3. Video Camera laser cutting machines. AZ-CCD Series
4. Auto Feeding and Unloading laser cutting machines. AZ-F Series
5. Rotary Lifted Flat laser cutting machines. AZ-U Series
6. Movable and Exchanging Table laser cutting machines. AZ-M Series
LASER MARKING MACHINE
1. Fiber laser marking machines. AZ-FB Series
2. CO2 Series laser marking machines. AZ-CO2 Series
3.3D Dynamic Focus Large-Scale laser marking machines. AZ-3D Series
4. End Pump laser marking machines. AZ-EP Series
5. On-Line laser marking machines. AZ-PF Series
6. Diode Pump (Side) series laser marking machines. AZ-DP Series
Sheet metal fiber laser cutting machine. ( widely used for cutting steel, Iron, Stainless steel, Aluminum, Copper and other metal materials)
Aotopto ceaselessly strengthens innovation of manufacturing, management and marketing. With many years efforts and innovation, Aotopto Laser has become a very famous laser equipment manufacturer not only in China but also in other countries in the world, supported by a huge sales network spreading more than 16 countries and regions.
We have exported our machines to many countries and supplied the professional laser application to our customers.
We can also manufacture the product designed by the customer' S requirement (OEM).
Everything feasible you require will be highly cooperated with: Price, transport, import duties, insurance, and taxes.
You only have to tell us what you want.
It is our honor to serve you.
Your trust and support would be the origin force to push us go further.
We promise we will provide products of better quality and our best service!
We guarantee that products at a competitive price and high quality. At present, our products have very good markets domestically and overseas. We wish to cooperate with you to create a bright future and gain mutual benefit.
Much appreciation for your prompt attention in advance, for more information, please contact us directly.
We are looking forward to forging a firm business relationship with you in the near future.
