Manual Punching Machine

Name: Manual Punching Machine
Brand: themouldinfo.com
SKU: 716413905
Availability: InStock
Rating: 4.3 (139 reviews)

Price:	US $ 950-1200/Piece
Trade Terms:	FOB,CIF,EXW
Min Order:	1/Piece
Pay Type:	L/C,T/T,Paypal,Money Gram,Western Union

Contact Supplier

Dongguan July Hydropneumatic Equipment Co., Ltd.

Showroom Product Company Profile

JLYB Air pneumatic presses

1) With compressed air as the power, simple to operate.

2) Making no noise during standby of the oil hydraulic system, saving the electricity and reducing
Production cost.

3) Cylinder stroke adjustable and custom-made for special request.

4) Simple to adjust the output, the required pressure can be reached simply adjusting the pneumatic

Pressure, easy and convenient.

5)Safe and human-centered design, comfortable and durable operation

6) Allows adding heating modules and temperature controller, as well as forcing transduce additionally.

7) Avaiilable working platforn: 500X 560X 610mm

Model	JLYB-100	JLYB-125	JLYB-160
Max Height	200	200	200
Cylinder Specification	Ø100*100mm	Ø125*100mm	Ø160*100mm
Adjustable Stroke	50mm	50mm	50mm
Power	AC220V,50Hz	AC220V,50Hz	AC220V,50Hz
Driving Pressure	0.4-0.7MPa	0.4-0.7MPa	0.4-0.7MPa
Weight	65kg	70kg	75kg
Driving Pressure	Theoretical output	Theoretical output	Theoretical output
0.4 MPa	294	458 Kgf	804 Kgf
0.5 MPa	368	573Kgf	1005Kgf
0.6 MPa	442	688Kgf	1206Kgf
0.7MPa	515	802	1320Kgf

items	JLYB hydropneumatic press machine
Action type	Double action
Action pressure	Clean compressed air of 4-7kgf
Anti-wear hydraulic oil	Anti-wear hydraulic oil of VG 68#
Operating temperature	0-60
Anti-pressure of pneumatic cylinder	12kg/ c
Frequency	20-30 times/min(related to stroke)

Prod Model:	JLYB
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Action:	Double Action
Material:	Steel
Brand:	July
Certificate:	CE/ISO9001
Warranty:	One Year
Power:	Pneumatic Force
Contact Person:	Sunny Tian
Telephone Number:	86 15876407183
Forging Forming Method:	Mold Forging

Our company was founded in Changhua County, Taiwan area in 1985. With more than 20 years' development, we have had strong technical force and advanced equipment such as the fully automated CNC machining center, milling machines and Germany-imported special testing tables of hydropneumatic pressure equipment, all of which ensure that our products can achieve the goal of long life, high precision, high output, small volume, zero leakage, and diversified characteristics.

All of our products are selling well in worldwide markets for our good quality, competitive price and prompt delivery, especially for our after-sales service. If you are interested in any of our products, please feel free to contact us for further information.
