Benifits of the melt filtration system for plastic extrusion machine
1, leak free mold
2, simple operation and uncomplicated screen change
3, high operational reliability
4, Easier access and less interference for the operator
5, no need to stop the working machine when chnage the screen
6, improve the quality and increase the output of the final products
Applications
PP/PE water pipe extrusion machine
PPR gas pipe extrusion machine
Plate/sheet extrusion machine
Cast film extrusion machine
PET monofilament extrusion machine
PET strap extrusion machine
ABS recycling pelletizer
Masterbatch
Type |
Screen D&A
| (mm)
overall dimension |
Heating power
(KW)) |
Output
(kg/h) |
| (mm) | (CM²) | L | W | H | L1 |
|
|
| GM-DP-R-80 | Φ60 | 28x2 | 180 | 170 | 280 | 700 | 2.4/3.2 | 30-180 |
| GM-DP-R-100 | Φ80 | 50x2 | 220 | 200 | 320 | 810 | 3.5/4.7 | 80-280 |
| GM-DP-R-120 | Φ100 | 78x2 | 250 | 220 | 360 | 970 | 5.0/7.2 | 220-480 |
| GM-DP-R-155 | Φ130 | 113x2 | 320 | 270 | 450 | 1100 | 8.2/11.1 | 300-700 |
| GM-DP-R-170 | Φ145 | 165x2 | 370 | 310 | 480 | 1320 | 9.4/12.7 | 400-1100 |
| GM-DP-R-195 | Φ165 | 214x2 | 400 | 380 | 550 | 1470 | 10.2/13.8 | 650-1500 |
| GM-DP-R-220 | Φ180 | 254x2 | 440 | 410 | 590 | 1620 | 13/17.5 | 800-1800 |
:,.
Remark: As the above specification is subject to change without prior notice |
Zhengzhou Great Machinery Co., Ltd is a company focus on the design and research of hydraulic screen changer, melt pump and extrusion dies. Gmach is a young company but has a large number of senior technicians, the deep technical background and full of passion work team determine it is standing on a high starting point. We do not just supply you the products, but also provide the solution to solve the problem.
We are committed to provide you the best products with ever improving design, strict production and quality control. Strong professional technical team provides you the perfect pre-sales and post-sales services.
Gmach's mission: Commit to plastic extrusion field, develop the environment friendly product, create a well-known brand at home and abroad
Now we have the following products
1, Plate type hydraulic screen changer GM-SSP series
2, Double plate type screen changer GM-DSP series
3, Double piston type continuous screen changer GM-DP-R series
4, Plate type continuous screen changer GM-R series
5, Automatic screen changer GM-ACB series
6, Large filtration area continuous screen changer GM-DP-L series
7, Spining pump
8, extrusion melt gear pump
9. Chemical pump
10, plastic recycling machine
11, plastic granules making mahcine pelletizing line
