New Product! ! ! High Quality Injection Plastic Mold for Plastic Drawer

New Product! ! ! High Quality Injection Plastic Mold for Plastic Drawer
Price: Negotiable/Piece
Trade Terms: FOB
Min Order: 1000/Piece
Pay Type: T/T
Specifications:
1. Plastic Injection Mold standard: HASCO, DME, MEUSBURGER, JIS, CHINA LKM STANDARD
2. Mold base: LKM&Hasco&DME standard (A, B plate 1730, 2311, 2312, P20 )
3. Material main core and cavity insert: DIN2312, 2738, 2344, 718, S136, 8407, NAK80, SKD61, H13
4. Hardness of steel: 46~56HRC
5. Material for Slider, Lifter and all sub insert use: 1.2767
6. Cavity: Single-cavity, Multi-cavity
7. A surface request: EDM & High Polish
8. Gate: Yudo/DME/HASCO/Synventive Hot runner, Cold runner
9. Maximum mold size: 1500*1500 mm
10. Mold life time: 500000~+1, 000, 000 shots
11. Quality: ISO9001-2008 certification
12. Product material: PA, PA6/6+GF, ABS, POM, PC, PP, PET, TPE, PVC, HDPE etc
13. Value-added service: Polish, texture, painting, screen printing, turnkey project
14. Lead time: 4~7 Weeks
15. Package: Wooden/Plywood case for tool, PE bags add export carton for parts
16. Payment terms: T/T
17. Trade terms: FOB Xiamen

Applications:
Automobile: Air outlet / vent, Rearview mirror, Instrument panel, Horn, seat
Electronic: Wireless receiver part, 3G/4G Modem Wireless Network Cards, USB housing, Mobile phone plastic part, remote control, key-press
Mechanical: Junction box, Motor support part, Pump plastic part, mower
Household: Industrial number calculator part, Juice cup, safety helmet
Medical: Hearing aids, Hollow fiber Dialyzer, Blood-Pressure meter, Stapler
Sport: Golf plastic part
Office: Secret code case part, Printer, duplicator, Atom seal
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Application: Car
Material: Stainless Steel
We manufacture and offer plastic injection mold (cold runner/ hot runner/ double color) and die casting mold. We can produce all kinds of standard according to international mold standard such as Hasco, Meusburger, Strack, DME by using the well accepted high quality steel. We also obtain DIN ISO/TS16949: 2009 & ISO9001: 2008 certificate.
