Pillow Block Bearing Advantages
1)High precision, long life, Low noise, low vibration
2)Easy for installation and unloading
3)Fast delivery, good quality
4)Wide inner ring with spherical outer ring
Description of Pillow Bock Bearing
1)The basic design of mounted bearing units is one bearing (insert bearing, which is a single row deep groove ball bearing with convex sphered outside) + a mounted bearing housing(which has a correspondingly sphered but concave bore).
2)The mounted bearing units are available in various different designs.
3)The main materials for the housing is cast iron.
4)The mounted bearing units are secured on the shaft via the bearing inner ring by: (1)set screws(SB Series); (2). Eccentric locking collar(SA Series); (3)Adapter sleeve (UK Series)
| d | D | B | C | C | C 0 | P u | SKF |
| mm | kN | kN | r/min | kg | - |
| 12 | 40 | 27, 4 | 12 | 9, 56 | 4, 75 | 0, 2 | 9500 | 0, 11 | YAR 203/12-2F |
| 12, 7 | 40 | 22, 5 | 12 | 9, 56 | 4, 75 | 0, 2 | 9500 | 0, 091 | YAT 203-008 |
| 12, 7 | 40 | 27, 4 | 12 | 9, 56 | 4, 75 | 0, 2 | 9500 | 0, 11 | YAR 203-008-2F |
| 12, 7 | 40 | 27, 4 | 12 | 9, 56 | 4, 75 | 0, 2 | 9500 | 0, 11 | YAR 203-008-2F/AH |
| 15 | 40 | 27, 4 | 12 | 9, 56 | 4, 75 | 0, 2 | 9500 | 0, 099 | YAR 203/15-2F |
| 15, 875 | 40 | 22, 5 | 12 | 9, 56 | 4, 75 | 0, 2 | 9500 | 0, 080 | YAT 203-010 |
| 15, 875 | 40 | 27, 4 | 12 | 9, 56 | 4, 75 | 0, 2 | 9500 | 0, 090 | YAR 203-010-2F |
| 15, 875 | 40 | 27, 4 | 12 | 9, 56 | 4, 75 | 0, 2 | 9500 | 0, 090 | YAR 203-010-2F/AH |
| 17 | 40 | 22, 1 | 12 | 9, 56 | 4, 75 | 0, 2 | 9500 | 0, 074 | YAT 203 |
| 17 | 40 | 27, 4 | 12 | 9, 56 | 4, 75 | 0, 2 | 9500 | 0, 088 | YAR 203-2F |
| 19, 05 | 47 | 25, 5 | 14 | 12, 7 | 6, 55 | 0, 28 | 8500 | 0, 11 | YAT 204-012 |
| 19, 05 | 47 | 31 | 14 | 12, 7 | 6, 55 | 0, 28 | 8500 | 0, 14 | YAR 204-012-2F |
| 19, 05 | 47 | 31 | 14 | 12, 7 | 6, 55 | 0, 28 | 8500 | 0, 14 | YAR 204-012-2F/AH |
| 19, 05 | 47 | 31 | 14 | 12, 7 | 6, 55 | 0, 28 | 5000 | 0, 14 | YAR 204-012-2RF |
| 19, 05 | 47 | 31 | 14 | 10, 8 | 6, 55 | 0, 28 | 5000 | 0, 14 | YAR 204-012-2RF/HV |
| 20 | 47 | 25, 5 | 14 | 12, 7 | 6, 55 | 0, 28 | 8500 | 0, 11 | YAT 204 |
| 20 | 47 | 31 | 14 | 12, 7 | 6, 55 | 0, 28 | 8500 | 0, 14 | YAR 204-2F |
| 20 | 47 | 31 | 14 | 12, 7 | 6, 55 | 0, 28 | 5000 | 0, 14 | YAR 204-2RF |
| 20 | 47 | 31 | 14 | 10, 8 | 6, 55 | 0, 28 | 5000 | 0, 14 | YAR 204-2RF/HV |
| 20 | 47 | 31 | 14 | 12, 7 | 6, 55 | 0, 28 | 5000 | 0, 14 | YAR 204-2RF/VE495 |
| 20, 637 | 52 | 34, 1 | 15 | 14 | 7, 8 | 0, 335 | 7000 | 0, 21 | YAR 205-013-2F |
| 22, 225 | 52 | 27, 2 | 15 | 14 | 7, 8 | 0, 335 | 7000 | 0, 17 | YAT 205-014 |
| 22, 225 | 52 | 34, 1 | 15 | 14 | 7, 8 | 0, 335 | 7000 | 0, 20 | YAR 205-014-2F |
| 22, 225 | 52 | 34, 1 | 15 | 14 | 7, 8 | 0, 335 | 7000 | 0, 20 | YAR 205-014-2F/AH |
| 23, 813 | 52 | 27, 2 | 15 | 14 | 7, 8 | 0, 335 | 7000 | 0, 15 | YAT 205-015 |
E-Asia was set up in 1996 and located at Jingjiang, a beautiful city in China. Our company is bearing manufacturer&bearing distributor. Since it was first established, E-AISA was dedicated in research, development and manufacture of bearings. Now, E-AISA has become main and one of the first grade suppliers of all kinds of bearings.
Our products include: Deep Groove Ball Bearings, Self-aligning Ball Bearings, Spherical Bearings, Tapered Roller Bearings, Cylindrical Roller Bearings, Needle Roller Bearings, Self-aligning Roller Bearings, Angular Contact Ball Bearings, Thrust Ball Bearings and Trust Roller Bearings and Special Bearings. We also provide OEM beaings.
E-Asia is a backbone enterprise for bearing production in China. With an area of 60, 000 square meters, more than 260 sets devices and machines, and around 200 employees, our company annually turns out more than 6 million sets bearings.
Our Bearings are exported to the USA, Canada, UK, Germany, Poland, Italy, Russia, the Middle East, Africa and other countries and regions of the world. E-Asia Bearing Co. Ltd. Is committed to the introduction of high-quality bearing products. Our company have more than 200 employees. Our brands include SKF bearings, NSK bearings, TIMKEN bearings, KOYO bearings, NTN bearings, IKO bearings and so forth.
Our belief is "Specialization is quality; Quality is the future. Any product with 0.01% defect is 100% reject" is our quality policy.
