Office Paper/Book Paper Making Machine

Office Paper/Book Paper Making Machine
Price: US $ 200000/Set
Trade Terms: FOB,CFR
Min Order: 1/Set
Pay Type: L/C,T/T
Technical Data:
1, Raw material: Waste paper,pure wood pulp

2, Output paper: printing paper;

3, Weight: 50-120g/m²

4, Capacity: 10-20T/D;

5, Net paper width: 2400mm;

6, Wire width:2950mm;

7,  Drive way: speed adjustment in AC frequency &processing transmission

8, Work speed: 70-180m/min

9,  Designed frame: Square frame, second self.

Main frame of equipments:
1, Fourdrinier part: The length of fourdrinier part is 13.5M, vacuum couch roll Φ650mm headbox (open style), moulding board,  scrape water board, stainless steel solder, faceplate box, macromolecule anti-grinding faceplate. Suction box: is made of stainless steel solder, faceplate box, macromolecule anti-grinding faceplate.  Roll: None slot roll with rubber covered, bearing style:1505.   Frame: square frame is made of steel.
2, Dryer part: Φ1500mm x 2950mm alloy dryer can 10 pieces, arrangement: 6 + sizing machine + 4, pneumatic loaded device, rubber hardness HSD 90°±2

3, Compression part:Φ600mm x 2950mm natural marble stone roller (1pc),Φ550mm x 2950mm rubber roller (1pc),Φ450mm x 2950mm natural marble stone roller (3 pcs),Φ400mm x 2950mm rubber roller (3pcs), rubber hardness HSD 90°C±2.

4, Reeling part: cylinder type winding machine.

5, Rewinding machine: rewinding machine 1 set.

6, Driving & control part: Equipped with 500 reducer,  Motors with AC  frequency convertor & adjustable speed,processing transmission.

Packaging
1. Fixed all the movable parts with plastic films.
2. Polystyrene foam plate wrapped around.
3. Wrapped with tighted plastic films several circles.
4. Fixed machine on the fumigated plywood pallet with iron wire.
5. Wrapped with wooden board around and nailed on.
Shipments;
1 sea transportation is from qingdao seaports or other ports.
2 the delivery time is decided by your needed machines or machine parts. But it also follows your needs.



Perfect service :
Pre-sale Service

     Send you different kinds of paper samples produced by our paper machine, after which you also can send us the

       paper sample you want to by DHL,EMS etc.Then we could design according to your requirement.
     Offer professional technical consultation services.

    Propose the most suitable scheme and equipment for our clients.

    Able to provide all-around turn-key projects as follows; production design,equipment manufacture,

       installation and adjustment, technical training for workers,conforming product.

    Complete sets machine will be pre installed and tested to confirm that the machine are in good condition before delivery.

    In time delivery.

After sale Service

    Arrange technicians to install and test the machine for you. They can also train your workers.

     One year guarantee time after the machine run well;

     Every 2 years,we can help to overhaul the complete machines for free;

     Supply you spare parts at a competitive price for a long time.


Brief introduction to Zhengzhou Guangmao Machinery Co. Ltd.:

     Founded in 1982, Zhengzhou Guangmao Machinery Co.,Ltd is a professional paper machine

       manufacturer who specialized in manufacturing and exporting paper machine over 30 years.

     Our products have passed Quality system ISO9001:2000 and exported more than 30 countries, such

       as Russia, India, Syria, Pakistan, Egept, Middle East, Africa, and South America etc. Our high quality

       and our perfect service has reserved consumer's praise and more orders.

Business scope:

    Various pulp making machine;

    Various paper making machine;

    Various paper processing machine;

    Various spare parts;

Company scale:

     Four branch factories;

     One International Trade Department;

     Total areas is 96,000square meters;

Technology strength:

    One professional technician team of 116 engineers and 12 experts;

    32 years rich practice experience;

    One innovative research team,always follow the advanced technology of Finland,Denmark and Italy;

    Skilled and careful workers;

Our market:

     Our machines sells well in more than 30 countries and regions,such as Russia,Indonesia,Uzbekistan,

Tajikstan,Nigeria,Uganda,Pakistan,Egypt,Bhutan,Fiji,Brazil,Paraguay,Syria,Libya,Turkey,Canada etc,

high quality and perfect service have reserved customer's praise and more orders, we also establish

good strategic cooperation with local distributor.

We have installed our paper production line in the following countries:
NOCOUNTRY NAMEPAPER PRODUCTION LINE
1Egypt1575 mm writing paper/ printing paper making machine
2Pakistan1880 mm toilet paper / tissue paper making machine
3Nigeria1880 mm toilet paper / tissue paper production line
4Fiji island1092 mm toilet tissue paper production line machine
5The kingdom of Bhutan787 mm writing paper/ copy paper making machines
6Afghanistan1880 mm toilet tissue paper production line machines
7Uzbekistan1092 mm toilet tissue paper production line
8Nigeria1880 mm toilet paper making line
9Tajikistan787 mm toilet paper production line (raw material:wheat straw)
10Uzbekistan787 mm toilet tissue paper making line ( raw material: wheat straw)
11Kazakhstan2100 mm kraft / fluting / paper production line
12Ghana1880 mm toilet tissue paper production line
13Bangladesh3200 mm kraft / corrugated/ medium paper production line
14Salvador1092 mm toilet paper/ tissue paper making machines
15Nigeria1575 mm toilet paper production line




FAQ
1.Why choose Guangmao?

       Founded in 1982, GM is a mature manufacturer in china with 32 years experience of

        manufacturing various kinds of paper machine.

      We strictly manufacture and manage according to IOS9001:2008 System. And our machine,

       which is running well in more than 30 countries, can match all the CE standard or more strict standard.

      We have a professional team with rich experience of paper mill design.you only

       need to tell us your open land dimension, we will make the future paper mill design for you.

       In time delivery.

2. What is your payment term?

      Usually, our payment term is 30% after signing contract, 70% before shipment.

      We can also accept L/C, Western Union;

      Payment term can be negotiated.

3. Could your engineer teach and train our worker and stay in our factory for long time?

      Yes,we have a team of 116 technical engineers, they can train and teach your worker to

       operate paper machine, during which their salary is paid by you.

4. Can I visit your company?

    Yes, you can. Our company located in zhengzhou city, the capital of Henan province in China, if you

take plane, it will need about 2 hours from guangzhou city, 1.5hours from shanghai city and 1 hour

from beijing city.we will pick you up from airport as well as the train station. We will take you to see

our machine running in our chinese clients' paper mill.welcome you and your team to visit us at any time!

Prod Model: 2400mm
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Raw Material: Wood/Bamboo Pulp, Waste Paper
Model: 2400mm
Capacity: 5t/D
Process: Paper Machine
Usage: Office Paper Machine
Automatic Grade: Automatic
Computerized: Yes
Sheet Former Type: Cylinder Mould
Paper Thickness: Normal Specification Paper
Certification: ISO
Condition: New
Type: Paper Processing Machinery
Zhengzhou guang mao machinery manufacturing Co., Ltd. is located in zhengzhou city, China. We are a leading and professional paper machine manufacturer in China.

We specialize in the manufacture of paper machines, paper processing machines and paper machine parts.

Our company has perfect service system. We have experienced engineer teams, who can supply perfect service during the whole deal, including technology consultation, civil work design, project evaluation; Installation and testing the whole production line; Training engineers and workers; Meanwhile, we also supply spare parts for long time and manufacture machines in accordance with customers' special requirements.

1. Following is main introduction of our company:

(1) total area of factory: 20, 000m2;

(2) total qty of workshop: 4;

(3) workers: 110 workers;

(4)engineer qty: 25 engineers;

2. Why you choose us?

(1) professional engineer team with 30years experience;

(2) we can supply you turn -key solution without any trouble;

(3) we have strict quality control system and ensure there is no unqualifiedly product;

(4) professional installation technician and clear technical training for your workers;

(5) strict recalling system: If any problem of machine, we will recall it and change a new one for free;

3. About shipment:

1. Sea transportation and rail way transportation is our main shipment way.

2 the delivery time is decided by your the machine model, we can also adjust delivery time according to your special requirement;

We hope to establish friendship and business relationship with friends from all over the world.
